Chapter 12 Description of Parameter Settings
ME300
12.1-09-11
Modbus
address
R/W Function
2202H R Actual output frequency (XXXXX Hz)
2203H R DC bus voltage (XXX.X V)
2204H R Output voltage (XXX.X V)
2205H R Power angle (XXX.X)
2206H R Display actual motor speed kW of U, V, W (XXXXX kW)
2207H R
Display motor speed in rpm estimated by the drive (XXXXX
rpm)
2208H R
Display positive / negative output torque in %, estimated by
the drive (+0.0: positive torque, -0.0: negative torque)
(XXX.X%)
2209H R Reserved
220AH R PID feedback value after enabling PID function (XXX.XX%)
220BH R
Display signal of AVI analog input terminal, 0-10 V
corresponds to 0.00–100.00% (see Explanation 1 in Pr.00-04)
220CH R
Display signal of ACI analog input terminal, 4–20 mA / 0–10 V
corresponds to 0.00–100.00% (see Explanation 2 in Pr.00-04)
220DH R Reserved
220EH R IGBT temperature of drive power module (XXX.X °C)
220FH R Reserved
2210H R
The status of digital input (ON / OFF), refer to Pr.02-12
(see NOTE 3 in Pr.00-04)
2211H R
The status of digital output (ON / OFF), refer to Pr.02-18
(see NOTE 4 in Pr.00-04)
2212H R The multi-step speed that is executing (S)
2213H R
The corresponding CPU pin status of digital input (d.)
(see NOTE 3 in Pr.00-04)
2214H R
The corresponding CPU pin status of digital output (O.)
(see NOTE 4 in Pr.00-04)
2215H R Reserved
2216H R Pulse input frequency (XXX.XX Hz)
2217H R Reserved
2218H R Reserved
2219H R Display times of counter overload (XXX.XX%)
221AH R GFF (XXX.XX%)
221BH R DC bus voltage ripples (XXX.X V)
221DH R Number of poles of a permanent magnet motor
221EH R User page displays the value in physical measure
221FH R Output value of Pr.00-05 (XXX.XX Hz)
2220H R Reserved
