Chapter 12 Description of Parameter Settings
ME300
12.1-09-12
Modbus
address
R/W Function
2221H R Reserved
2222H R Reserved
2223H R Control mode of the drive. 0: speed mode 1: torque mode
2224H R Carrier frequency of the drive (XX kHz)
2225H R Reserved
2226H R
Drive status
bit 1–0
00b: No direction
01b: Forward
10b: Reverse
bit 3–2
01b: Drive ready
10b: Error
bit 4
0b: Motor drive did not output
1b: Motor drive did output
bit 5
0b: No alarm
1b: Alarm
2227H R
Drive’s estimated output torque (positive or negative direction)
(XXXX Nt-m)
2228H R Reserved
2229H R Accumulate KWH display (XXXX.X)
222AH R Reserved
222BH R Reserved
222CH R Reserved
222DH R Reserved
222EH R PID reference (XXX.XX%)
222FH R PID offset (XXX.XX%)
2230H R PID output frequency (XXX.XX Hz)
2231H R Reserved
2232H R Display auxiliary frequency
2233H R Display master frequency
2234H R
Display frequency after addition and subtraction of auxiliary
and master frequencies.
5. Exception response
When the drive is using the communication connection, if an error occurs, the drive responds
to the error code and sets the highest bit (bit 7) of code to 1 (function code AND 80H) then responds
to the control system to signal that an error occurred.
If the keypad displays “CE-XX” as a warning message, “XX” is the error code at that time.
Refer to the table of error codes for communication error for reference.
