Delta ME300 Series - Page 365

Chapter 12 Description of Parameter Settings
ME300
12.1-13-2
Pr. Explanation Settings
01-13 Deceleration time 1 15 (sec.)
01-43 V/F curve selection 2 (V/F curve to the power of 2)
02-05 Multi-function input command 5 (MI5)
15: Rotating speed command from
AVI
02-16 Multi-function output 2 (MO1) 11 (Malfunction indication)
03-00 Analog input selection (AI) 1 (Frequency command)
03-28 AI terminal input selection
0 (0
–10 V)
03-50 Analog input curve selection 1 (three-point curve of AVI)
07-06 Restart after momentary power loss
2 (Speed tracking by the minimum
output frequency)
07-11 Number of times of restart after fault 5 (times)
07-33 Auto-restart interval of fault 60 (sec.)
 Group setting 04: Pump
The following table lists the relevant pump setting application parameters.
Pr. Explanation Settings
00-11 Speed control mode 0 (VF)
00-16 Load selection 0 (Normal load)
00-20
Master frequency command source
(AUTO, REMOTE)
2 (External analog input)
00-21 Operation command source (AUTO, REMOTE) 1 (External terminals)
00-23 Motor direction control 1 (Disable reverse)
01-00 Motor 1 maximum operation frequency Default setting
01-01 Output rated / base frequency of motor 1 Default setting
01-02 Motor 1 output voltage Default setting
01-03 Motor 1 mid-point frequency 1 Default setting
01-04 Motor 1 mid-point voltage 1 Default setting
01-05 Motor 1 mid-point frequency 2 Default setting
01-06 Motor 1 mid-point voltage 2 Default setting
01-07 Motor 1 minimum output frequency Default setting
01-08 Motor 1 minimum output voltage Default setting
01-10 Output frequency upper limit 50.00 (Hz)
01-11 Output frequency lower limit 35.00 (Hz)
01-12 Acceleration time 1 15.00 (sec.)
01-13 Deceleration time 1 15 (sec.)
01-43 V/F curve selection 2 (V/F curve to the power of 2)
07-06 Restart after momentary power loss
2 (Speed tracking by the minimum
output frequency)
07-11 Number of times of restart after fault 5 (times)
07-33 Auto-restart interval of fault 60 (sec.)
