Installation and Operation Manual for RPI M6A M8A M10A inverters V1.0 2016-02-03
9 Measurements and statistics
9.4 Inverter information
Description
In this section you nd general information about the inverter.
Accessing the Menu
Main menu > Event log
1. When the default information is displayed, press any button to open the main menu. Oth-
erwise, repeatedly press the button
ESC
until the main menu is displayed.
2. Use the buttons and to select Inverter Info.
To conrm your selection, press the button
ENT
.
3. Use the buttons and to scroll through the inverter information.
Displayed Parameters
Parameter Description
S/N
Serial number.
DSP, Red, Comm, Wi
The software versions of the various controllers.
ID
The currently set inverter ID for RS485. For a description how to change the inverter ID, see “8.6 Inverter
ID”, p. 70.
Country
The currently set country/grid.
Insulation
The currently set insulation resistance in kΩ. For a description how to change the insulation settings, see
“8.7 Insulation mode and insulation resistance”, p. 71.
Baud rate
The currently set baud rate for RS485. For a description how to change the baud rate, see “8.5 Baud rate
for RS485”, p. 69.
Install
The date of installation.
AC connection
The currently chosen type of AC connection. For a description how to set a different type of AC connec-
tion, see “8.11 AC Connection type”, p. 82.
Pmax
The currently set maximum active power that the inverter feeds into the grid. For a description how to
change the maximum active power, see “8.12 Max. Power (Maximum feed-in power)”, p. 83.
