Installation and Operation Manual for RPI M6A M8A M10A inverters V1.0 2016-02-03
4 Product overview
4.4 Electrical connectors
4.4.1 Overview
RS485AC/DC Disconnection switch
AC ConnectorDC inputs
Communication port
Fig. 4.2: Overview electrical connectors RPI M6A and M8A
RS485AC/DC Disconnection switch
AC ConnectorDC inputs
Communication port
Fig. 4.3: Overview electrical connectors RPI M10A
Component / connector Description
AC/DC Disconnection switch
See “4.4.2 AC/DC disconnection switch”, p. 14
DC connectors (DC inputs)
See “4.4.4 DC connectors (DC inputs)”, p. 15
RS485 port
See “4.4.5 RS485 port”, p. 15
AC connector
See “4.4.3 AC connector (AC output)”, p. 14
Communication port
See “4.4.6 Communication port 2”, p. 15
