Delta RPI M6A

13 Technical data
Installation and Operation Manual for RPI M6A M8A M10A inverters V1.0 2016-02-03
114
Mechanical Design RPI M6A RPI M8A RPI M10A
Dimensions (W x H x D) 510 x 445 x 177 mm
Weight 25 kg 25 kg 26 kg
Cooling Natural convection
AC Connector type Amphenol C16-3
DC Connector type Multi-Contact MC4
Communication interfaces 2 x RS485, 1 x Dry contacts, 1 x EPO (External Power Off), 6 x Digital inputs
General Specication RPI M6A RPI M8A RPI M10A
Delta model name RPI M6A RPI M8A RPI M10A
Delta part number RPI602FA0E1000 RPI802FA0E1000 RPI103FA0E1000
Maximum efciency 98.3% 98.3% 98.3%
EU efciency 97.6% 97.9% 98.0%
Operating temperature range -25 ... +60 °C
Operating temperature range without derating -25 ... +40 °C
Storage temperature range -25 ... +60 °C
Relative humidity 0 ... 100 %, non-condensing
Maximum operating altitude 2000 m above sea level
Standards and Directives RPI M6A RPI M8A RPI M10A
Protection degree IP65
Safety class I
Pollution degree II
Overload behavior Current limitation; power limitation
Safety IEC 62109-1 / -2, CE compliance
EMC EN 61000-6-2, EN 61000-6-3
Immunity IEC 61000-4-2 / -3 / -4 / -5 / -6 / -8
Harmonics EN 61000-3-2 EN 61000-3-12
Variations and icker EN 61000-3-3 EN 61000-3-11
Grid interfaces
For Europe: see www.solar-inverter.com
For Australia/New Zealand: AS3100 / AS4777
1)
When operated with balanced DC inputs (50/50 %)
2)
IEC 60664-1, IEC 62109-1
3)
The maximum AC apparent power indicates the power an inverter is able to deliver. This maximum apparent power may not necessarily be reached.
4)
Limited to 4.99 kVA when grid type “AU/NZ PL 4.99k” is selected.
4)
AC voltage and frequency range will be programmed according to the individual country requirements.
