Installation and Operation Manual for RPI M6A M8A M10A inverters V1.0 2016-02-03
8 Settings
P(V)
Power vs. Frequency
Power Limit
5. Use the buttons and to select Power vs Frequency. The current setting is
displayed behind the menu entry.
F Recovery: 50.20Hz
Gradient: 100%
F Start: 50.20Hz
Mode: ON
6. To change the mode, use the buttons and and press the button
ENT
.
To switch the function on, select ON and press the button
ENT
.
To switch the function off, select OFF and press the button
ENT
. When you switch the
function off, you can ignore the following steps.
F Recovery: 50.20Hz
Gradient: 100%
F Start: 50.20Hz
Mode: ON
7. Use the buttons and to select a parameter and press the button
ENT
.
8. To change the parameter value, use the buttons and .
To conrm your setting, press the button
ENT
.
To cancel the action, press the button
ESC
.
9. Repeat steps 7 to 8 for all parameters you want to change.
Congurable Parameters
Parameter Description Value range
Mode
Switches the function on and off.
ON | OFF
Default value: OFF
F Start
The grid frequency at which the inverter starts to limit the active
power according to the Gradient parameter.
50.00 .. 55.00 Hz
Default value: according to the
country regulations
F Recovery
The grid frequency at which the inverter reconnects to the grid or at
which the inverter feeds-in full power again. The behavior depends on
the selected country and grid.
50.00 .. 55.00 Hz
Default value: according to the
country regulations
Gradient
Adjustment of the active power fed into the grid in percent per Hz
when the grid frequency is between F Start and F Stop.
0 .. 100 %/Hz
T Recovery
When the grid frequency drops to F Recovery, the inverter will wait
for the time dened in T Recovery before it returns to normal operat-
ing behavior.
0 .. 600 s
Do not change this setting without prior
consultation with Delta Solar Support.
