Status value Description How to correct
0x1002（4098）
An error occurs in the special
modules on the right of RTU-ECAT
1. Ensure that the power supply to the right-
side
special modules is normal.
2. Check the error information
of the special
modules on the right of RTU-ECAT.
Configure the error status CR registers for
the
right-
side special modules to the input data of IO
data and then get to know the cause based on
the values in the error status CRs.
Refer to error status CRs in DVP-
PLC
Application Manual: Special Modules for more
details on error codes of special modules.
0x1004（4100）
The modules configured in the
software are inconsistent with those
actually connected and meanwhile an
error in extension modules on the
right of RTU-ECAT occurs.
1. Ensure the module
s configured in the software
match those actually connected.
2. Ensure the power supply to the right-
side
modules works normally.
3. Check the error information of the right-
side
modules and then get rid of it according to the
instructions in the module manual.
0x1005（4101）
The special modules configured on
the right of RTU-ECAT exceeds 8
units.
Ensure that the number of special modules
configured in the software is no more than 8 units.
 LV state（voltage status）
Bit Value Description How to correct
Bit 0
0
The voltage for RTU-ECAT is
normal.
--
1
The voltage for RTU-ECAT is
abnormal.
Check if the voltage of the power
supply to RTU-ECAT is normal.
Bit 1~bit 7 0/1 Reserved Reserved
 Error module number（The number of the right-side module in error）
Bit Value Description How to correct
Bit 0 0
The 1
st
special module on the rig
ht
of RTU-ECAT is normal.
--
