Measurements and Messages
Table 9.4.: Actual Data Pages Measurement and Description
E
F
G
B
H
B
C
D
A
Figure 9.5.: Measurements of Temperature on the Actual Data Pages
Temperature
A Inside max. The maximum inverter inner temperature value
B Inside min. The minimum inverter inner temperature value
C Heatsink-1 max. The maximum Heatsink-1 temperature value
D Heatsink-1 min. The minimum Heatsink-1 temperature value
E Heatsink-2 max. The maximum Heatsink-2 temperature value
F Heatsink-2 min. The minimum Heatsink-2 temperature value
G Heatsink-3 max. The maximum Heatsink-3 temperature value
H Heatsink-3 min. The minimum Heatsink-3 temperature value
Table 9.5.: Temperature Measurement and Description
