Product Overview
Communication
Connections
LCD/LED Display
Buttons
Label
Air outlets
DC Connectors
AC Connector
Fan *4
*Note: The fans shown are without
the required protective screen for
illustrative purposes
Please note the 15 TL / 20 TL model
is shown here. The 30 TL will look
slightly different - a different AC
connector and 2 addl. DC inputs will
be present on the 30 TL.
Figure 4.4.: 15 TL / 20 TL / 30 TL Inverter Exterior View
➀
Figure 4.5.: Grounding Kit
