Product Overview
4.3 Function Introduction
Inverter exterior features are shown on gure 4.3 and 4.4, and a more detailed description is
found in the sections from 4.3.1 to 4.3.3
*Note: The fan is shown without
the required protective screen for
illustrative purposes
Communication
Connections
LCD/LED Display
Buttons
Label
Air outlets
DC Connectors
AC Connector
Fan
Figure 4.3.: 10 TL Inverter Exterior View
