Video section
• Standard video connectors
Input / output level and impedance:
1 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +0, –3 dB
• S-Video connectors
Input / output level and impedance:
Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
C (color) signal — 0.3 (PAL) / 0.286 (NTSC) Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +0, –3 dB
• Color component video connector
Input / output level and impedance:
Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
P
B / CB signal — 0.7 Vp-p, 75 Ω/ohms
P
R / CR signal — 0.7 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 100 MHz — +0, –3 dB (when video convert set to “OFF”)
n
Tuner section [FM] [AM]
(note: µV at 75 Ω/ohms, 0 dBf = 1 x 10
-15
W)
Receiving Range: 87.5 MHz ~ 108.0 MHz 522 kHz ~ 1611 kHz
Usable Sensitivity: 1.0 µV (11.2 dBf) 18 µV
50 dB Quieting Sensitivity: MONO 1.6 µV (15.3 dBf)
STEREO 23 µV (38.5 dBf)
S/N (IHF-A): MONO 77 dB
STEREO 72 dB
Total harmonic Distortion (at 1 kHz): MONO 0.15 %
STEREO 0.3 %
n
DAB section
Frequency range: 174.928 (5A) ~ 239.200 (13F) MHz (BAND III)
1452.960 (LA) ~ 1490.624 (LW) MHz (L–BAND)
Sensitivity: –98 dBm (BAND III) –94 dBm (L-BAND)
S/N: 100 dB (IHF-A weighted)
THD+N: 0.006 % (1 kHz)
Channel separation:
95 dB (1 kHz)
Frequency response:
+0.5/–0.5 dB (20 Hz ~ 20 kHz)
Aerial terminal:
75 Ω/ohm, F female
n
Wireless LAN
Network type (wireless LAN standards) :
Conforming to IEEE 802.11b
Conforming to IEEE 802.11g
(Conforming to Wi-Fi
®
)
z
Transfer rate: DS-SS: 11 / 5.5 / 2 / 1 Mbps (Automatic switching)
OFDM: 54 / 48 / 36 / 24 / 18 / 12 / 9 / 6 Mbps (Automatic switching)
Security: SSID (Network name)
WEP key (network key) (64/128 bits)
WPA-PSK (TKIP/AES)
WPA2-PSK (TKIP/AES)
Used frequency range:
2,412 MHz ~ 2,472 MHz
No. of channels:
Conforming to IEEE 802.11b : 13ch (DS-SS) (Of which 1 channel used)
Conforming to IEEE 802.11g : 13ch (OFDM) (Of which 1 channel used)
n
General
Power supply: AC 230 V, 50 Hz
Power consumption:
580 W
0.3 W (Standby)
Maximum external dimensions:
434 (W) x 195 (H) x 455 (D) mm
Weight: 18.9 kg
n
Main remote control unit (RC-1068)
Batteries: LR6/AA Type (two batteries)
Maximum external dimensions:
63 (W) x 238 (H) x 31 (D) mm
Weight: 190 g (including batteries)
n
Sub remote control unit (RC-1070)
Batteries: R03/AAA Type (two batteries)
Maximum external dimensions:
49 (W) x 220 (H) x 24.5 (D) mm
Weight: 114 g (including batteries)
z: Wi-Fi
®
conformity indicates tested and proven interoperability by the “Wi-Fi Alliance”, a group certifying interoperability
among wireless LAN devices.
b
For purposes of improvement, specifications and design are subject to change without notice.
