Denon AVR-4310CI - Checking Unit Status and Information; Viewing Current Settings and Signal Status; Auto Surround Mode and Quick Select Status

8
Getting Started Connections Settings Remote ControlMulti-zone Information Troubleshooting Specifi cations
Setting items Setting contents
Quick Select
Shows information about
“Saving Frequently Used
Settings (Quick Select
Function)” (vpage 82)
settings.
Quick Select 1 / Quick Select 2 / Quick Select 3 / ZONE2 Quick Select
/ ZONE3 Quick Select
Select Source / Video Select / MultEQ XT / Dynamic EQ / Dynamic
Volume / Auto Surround Mode (Analog/PCM 2ch / Digital 2ch /
Digital 5.1ch / Multi ch) / Volume Level
•
Preset Channel
Shows information about
preset channels.
This can be checked when the input source is set to
NET/USB
XM
SIRIUS HD Radio
.
A / B / C / D / E / F / G
A1 ~ A8 / B1 ~ B8 / C1 ~ C8 / D1 ~ D8 / E1 ~ E8 / F1 ~ F8 / G1 ~ G8•
Checking the Status (Information)
Setting items Setting contents
Status
Shows information about
current settings.
MAIN ZONE
Shows information about settings for MAIN ZONE.
The items displayed differ according to the input source.
Select Source / Name / Zone Rename / Surround Mode / Input Mode
/ Decode Mode / HDMI / Digital / Component / iPod dock / Rec Select
/ Video Select / Video Convert / i/p Scaler / Resolution / Progressive
Mode / Aspect etc.
n
ZONE2 / ZONE3
Shows information about settings for multi-zone.
Zone Rename / Power / Select Source / Volume Level
n
Audio Input Signal
Shows information about
audio input signals.
Surround Mode : The currently set surround mode
Signal : The input signal type
fs : The input signal’s sampling frequency
Format : The number of channels in the input signal (front, surround,
LFE)
Offset : The dialogue normalization correction value
Flag : This is displayed when inputting signals including a surround back
channel. “MATRIX” is displayed with Dolby Digital EX and DTS-ES Matrix
signals, “DISCRETE” with DTS-ES Discrete signals.
Dialogue normalization function
This is automatically activated when playing Dolby Digital sources.
This function automatically corrects the standard signal level for individual
program sources.
The correction value can be checked using the <STATUS>.
The fi gure is the correction value when the standard level is corrected.
HDMI Information
Shows information about
HDMI input/output signals
and monitor.
Signal Info.
Resolution / Color Space / Pixel Depth•
Monitor 1 / Monitor 2
Interface / Supported resol.•
Auto Surround
Mode
Shows information about auto
surround mode settings.
Analog/PCM 2ch / Digital 2ch / Digital 5.1ch / Multi ch
This can be displayed when “Auto Surround Mode” is set to “ON”.
Playback
Main remote control
operation buttons
:Displaying the menu
Cancel the menu
:Moves the cursor
(Up/Down/Left/Right)
:Confi rm the setting :Return to previous menu
