Connections Settings Playback Remote ControlMulti-zone Information Troubleshooting Specifications
t
e
y
u i
o
Q0
Q3Q4Q4
Q9
Q9
Q1
Q2
q
r
w
Q6
Q7Q8
Q5
W0W1W0
Part Names and Functions
q SIRIUS connector ······································· (19)
w RS-232C connector ····································· (22)
e REMOTE CONTROL jacks ·························· (22)
r TRIGGER OUT jacks ··································· (22)
t DOCK CONTROL jack ································· (16)
y Speaker terminals ······································ (13)
u SIGNAL GND terminal ······························· (16)
i AC inlet ························································ (24)
o AC OUTLETS ··············································· (24)
Q0 HD Radio antenna terminals ··············· (19, 20)
Q1 ETHERNET connector ································ (23)
Q2 USB (iPod DIRECT) port ····························· (21)
Q3 XM connector ············································· (18)
Q4 Digital audio connectors ···················· (15 ~ 19)
Q5 DENON LINK connector ····························· (20)
Q6 COMPONENT VIDEO connectors ·········(15, 17)
Q7 HDMI connectors ········································ (14)
Q8 VIDEO / S-VIDEO connectors ············ (15 ~ 18)
Q9 Analog audio connectors ··················· (15 ~ 18)
W0 PRE OUT connectors ···························· (22, 86)
W1 EXT. IN connectors ····································· (21)
Rear Panel
Getting Started
1.AVR4310CIEU.indd 6 2009/04/14 16:35:56
To Next Page
