Denon AVR-4520 Service Manual

117
5.4. MHL
YES
YES
YES
YES
YES
YES
No picture or sound is output.
(1) Check if the MHL cable is detected.
When the MHL cable is connected, can "High” be seen for 4pin
on N1101 (8U-310116)?
(3) Check power supply (8U-310116) .
Are 3.3V supplied to N1701 5pin?
Are 1.2V supplied to N1701 6pin?
Are 5V supplied to N1101 12pin?
(4) Check RESET.
Is RESET waveform conrmed in N1101 (8U-310116) 8pin,
when the power is turned on? (If the waveform is not the
reference waveform, proceed to NO.)
(5) Check Control signal (I2C).
Is waveform conrmed in N1101 5pin/7pin (8U-310116), when
the power is turned on? (If the waveform is not the reference
waveform, proceed to NO.)
(6) Check the DDC waveform.
Can the waveform be seen for 9pin/10pin on N1101 (8U-310116)?
(2) Check the VBUS(5V) output.
When the MHL cable is connected, can "5V” be seen for 1pin on
N1701 (8U-310116)?
The MHL cable is defective.
Q804, Q805 and surrounding circuitry (8U-
310115-3) are defective.
The power supply circuitry is defective.
8U-310116
U1708 (3.3V)
U1709 (1.2V)
Q1725 (5V)
The RESET circuitry (8U-310116) or U802
(8U-310115-3) is defective.
Replace the new parts.
Q1108 (8U-310116) or the pattern is
defective of I2C line.
U800 or U802 and surrounding circuitry (8U-
310115-3) are defective.
U1707 and surrounding circuitry (8U-
310116) are defective.
NO
NO
NO
NO
NO
NO
Please refer to the "AVR4520_HDMI Rx-Tx Failure Detection
Procedure Manual ver_1.00" of SDI.

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
