Denon AVR-4520 Service Manual

243
P.AMP PWB ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
D0101,0102 00D2760794900 KDS160-RTK/P
D0105 00D2760794900 KDS160-RTK/P
D0110 00D2760794900 KDS160-RTK/P
D0201,0202 00D2760794900 KDS160-RTK/P
D0205 00D2760794900 KDS160-RTK/P
D0210 00D2760794900 KDS160-RTK/P
D0301,0302 00D2760794900 KDS160-RTK/P
D0305 00D2760794900 KDS160-RTK/P
D0310 00D2760794900 KDS160-RTK/P
D0401,0402 00D2760794900 KDS160-RTK/P
D0405 00D2760794900 KDS160-RTK/P
D0410 00D2760794900 KDS160-RTK/P
D0501,0502 00D2760794900 KDS160-RTK/P
D0505 00D2760794900 KDS160-RTK/P
D0510 00D2760794900 KDS160-RTK/P
D0601,0602 00D2760794900 KDS160-RTK/P
D0605 00D2760794900 KDS160-RTK/P
D0610 00D2760794900 KDS160-RTK/P
D0701,0702 00D2760794900 KDS160-RTK/P
D0705 00D2760794900 KDS160-RTK/P
D0710 00D2760794900 KDS160-RTK/P
D0801,0802 00D2760794900 KDS160-RTK/P
D0805 00D2760794900 KDS160-RTK/P
D0810 00D2760794900 KDS160-RTK/P
D0901,0902 00D2760794900 KDS160-RTK/P
D0905 00D2760794900 KDS160-RTK/P
D0910 00D2760794900 KDS160-RTK/P
Q0101 21785000550AS HN4A06J
Q0102 00D2730479909 2N5551S-RTK/P
Q0103 00D2710318909 2N5401S-RTK/P
Q0104 00D2730479909 2N5551S-RTK/P
Q0105 00D2710318909 2N5401S-RTK/P
Q0106 00D2730479909 2N5551S-RTK/P
Q0107 00D2710318909 2N5401S-RTK/P
Q0110 00D2710318909 2N5401S-RTK/P
Q0111 00D2730479909 2N5551S-RTK/P
Q0112 00D2710318909 2N5401S-RTK/P
Q0113 00D2730479909 2N5551S-RTK/P
Q0201 21785000550AS HN4A06J
Q0202 00D2730479909 2N5551S-RTK/P
Q0203 00D2710318909 2N5401S-RTK/P
Q0204 00D2730479909 2N5551S-RTK/P
Q0205
00D2710318909 2N5401S-RTK/P
Q0206 00D2730479909
2N5551S-RTK/P
Q0207 00D2710318909 2N5401S-RTK/P
Q0210 00D2710318909 2N5401S-RTK/P
Q0211 00D2730479909 2N5551S-RTK/P
Q0212 00D2710318909 2N5401S-RTK/P
Q0213 00D2730479909 2N5551S-RTK/P
Q0301 21785000550AS HN4A06J
Q0302 00D2730479909 2N5551S-RTK/P
Q0303 00D2710318909 2N5401S-RTK/P
Q0304 00D2730479909 2N5551S-RTK/P
Q0305 00D2710318909 2N5401S-RTK/P
Q0306 00D2730479909 2N5551S-RTK/P
Q0307 00D2710318909 2N5401S-RTK/P
Q0310 00D2710318909 2N5401S-RTK/P
Q0311 00D2730479909 2N5551S-RTK/P
Q0312 00D2710318909 2N5401S-RTK/P
Q0313 00D2730479909 2N5551S-RTK/P
Q0401 21785000550AS HN4A06J
Q0402 00D2730479909 2N5551S-RTK/P
Q0403 00D2710318909 2N5401S-RTK/P
Q0404 00D2730479909 2N5551S-RTK/P

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
