Denon AVR-4520 Service Manual

244
Ref. No. Part No. Part Name Remarks Q'ty New
Q0405 00D2710318909 2N5401S-RTK/P
Q0406 00D2730479909 2N5551S-RTK/P
Q0407 00D2710318909 2N5401S-RTK/P
Q0410 00D2710318909 2N5401S-RTK/P
Q0411 00D2730479909 2N5551S-RTK/P
Q0412 00D2710318909 2N5401S-RTK/P
Q0413 00D2730479909 2N5551S-RTK/P
Q0501 21785000550AS HN4A06J
Q0502 00D2730479909 2N5551S-RTK/P
Q0503 00D2710318909
2N5401S-RTK/P
Q0504 00D2730479909 2N5551S-RTK/P
Q0505 00D2710318909 2N5401S-RTK/P
Q0506 00D2730479909 2N5551S-RTK/P
Q0507 00D2710318909 2N5401S-RTK/P
Q0510 00D2710318909 2N5401S-RTK/P
Q0511 00D2730479909 2N5551S-RTK/P
Q0512 00D2710318909 2N5401S-RTK/P
Q0513 00D2730479909 2N5551S-RTK/P
Q0601 21785000550AS HN4A06J
Q0602 00D2730479909 2N5551S-RTK/P
Q0603 00D2710318909 2N5401S-RTK/P
Q0604 00D2730479909 2N5551S-RTK/P
Q0605 00D2710318909 2N5401S-RTK/P
Q0606 00D2730479909 2N5551S-RTK/P
Q0607 00D2710318909 2N5401S-RTK/P
Q0610 00D2710318909 2N5401S-RTK/P
Q0611 00D2730479909 2N5551S-RTK/P
Q0612 00D2710318909 2N5401S-RTK/P
Q0613 00D2730479909 2N5551S-RTK/P
Q0701 21785000550AS HN4A06J
Q0702 00D2730479909 2N5551S-RTK/P
Q0703 00D2710318909 2N5401S-RTK/P
Q0704 00D2730479909 2N5551S-RTK/P
Q0705 00D2710318909 2N5401S-RTK/P
Q0706 00D2730479909 2N5551S-RTK/P
Q0707 00D2710318909 2N5401S-RTK/P
Q0710 00D2710318909 2N5401S-RTK/P
Q0711 00D2730479909 2N5551S-RTK/P
Q0712 00D2710318909 2N5401S-RTK/P
Q0713 00D2730479909 2N5551S-RTK/P
Q0801 21785000550AS HN4A06J
Q0802 00D2730479909 2N5551S-RTK/P
Q0803 00D2710318909
2N5401S-RTK/P
Q0804 00D2730479909 2N5551S-RTK/P
Q0805 00D2710318909 2N5401S-RTK/P
Q0806 00D2730479909 2N5551S-RTK/P
Q0807 00D2710318909 2N5401S-RTK/P
Q0810 00D2710318909 2N5401S-RTK/P
Q0811 00D2730479909 2N5551S-RTK/P
Q0812 00D2710318909 2N5401S-RTK/P
Q0813 00D2730479909 2N5551S-RTK/P
Q0901 21785000550AS HN4A06J
Q0902 00D2730479909 2N5551S-RTK/P
Q0903 00D2710318909 2N5401S-RTK/P
Q0904 00D2730479909 2N5551S-RTK/P
Q0905 00D2710318909 2N5401S-RTK/P
Q0906 00D2730479909 2N5551S-RTK/P
Q0907 00D2710318909 2N5401S-RTK/P
Q0910 00D2710318909 2N5401S-RTK/P
Q0911 00D2730479909 2N5551S-RTK/P
Q0912 00D2710318909 2N5401S-RTK/P
Q0913 00D2730479909 2N5551S-RTK/P
RESISTORS GROUP
R0102 nsp RD14B2E152JT(5)
R0103 nsp RD14B2E333JT(5)

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
