Denon AVR-4520 Service Manual

245
Ref. No. Part No. Part Name Remarks Q'ty New
R0104 nsp RM73B--471JT +1608
R0105 nsp RM73B--102JT +1608
R0106,0107 nsp RM73B--471JT +1608
R0108 nsp RD14B2E122JT(5)
R0109 nsp RD14B2E333JT(5)
R0110 00MGG0547116X 470 OHM +- 5% 1/6W
R0111 00MGG0522116X 220 OHM +- 5% 1/6W
R0112 nsp RD14B2E473JT(5)
R0114 00MGG0547116X 470 OHM +- 5% 1/6W
R0118,0119 00MGG0547016X 47 OHM +- 5% 1/6W
R0120 nsp RM73B--334JT +2125
R0121 nsp RM73B--473JT +1608
R0122-0125 nsp RS14B3DR47JNBST(S)
R0126-0128 nsp RM73B--103JT +1608
R0129 nsp RM73B--154JT +2125
R0130 nsp RM73B--562JT +1608
R0131 nsp RM73B--103JT +1608
R0132 nsp RM73B--223JT +1608
R0133 nsp RM73B--333JT +1608
R0134 nsp RD14B2E100JT(5)
R0135 nsp RS14B3D100JNBST(S)
R0136 00MGG0547116X 470 OHM +- 5% 1/6W
R0137 00MGG0522116X 220 OHM +- 5% 1/6W
R0138 nsp RM73B--0R0KT +1608
R0202 nsp RD14B2E152JT(5)
R0203 nsp RD14B2E333JT(5)
R0204 nsp RM73B--471JT +1608
R0205 nsp RM73B--102JT +1608
R0206,0207 nsp RM73B--471JT +1608
R0208 nsp RD14B2E122JT(5)
R0209 nsp RD14B2E333JT(5)
R0210 00MGG0547116X 470 OHM +- 5% 1/6W
R0211 00MGG0522116X 220 OHM +- 5% 1/6W
R0212 nsp RD14B2E473JT(5)
R0214 00MGG0547116X 470 OHM +- 5% 1/6W
R0218,0219 00MGG0547016X 47 OHM +- 5% 1/6W
R0220 nsp RM73B--334JT +2125
R0221 nsp RM73B--473JT +1608
R0222-0225 nsp RS14B3DR47JNBST(S)
R0226-0228 nsp RM73B--103JT +1608
R0229 nsp RM73B--154JT +2125
R0230 nsp RM73B--562JT +1608
R0231 nsp
RM73B--103JT +1608
R0232 nsp RM73B--223JT +1608
R0233 nsp RM73B--333JT +1608
R0234 nsp RD14B2E100JT(5)
R0235 00D2442671901 RS14B3D100JNBST(S)
R0236 00MGG0547116X 470 OHM +- 5% 1/6W
R0237 00MGG0522116X 220 OHM +- 5% 1/6W
R0238 nsp RM73B--0R0KT +1608
R0302 nsp RD14B2E152JT(5)
R0303 nsp RD14B2E333JT(5)
R0304 nsp RM73B--471JT +1608
R0305 nsp RM73B--102JT +1608
R0306,0307 nsp RM73B--471JT +1608
R0308 nsp RD14B2E122JT(5)
R0309 nsp RD14B2E333JT(5)
R0310 00MGG0547116X 470 OHM +- 5% 1/6W
R0311 00MGG0522116X 220 OHM +- 5% 1/6W
R0312 nsp RD14B2E473JT(5)
R0314 00MGG0547116X 470 OHM +- 5% 1/6W
R0318,0319 00MGG0547016X 47 OHM +- 5% 1/6W
R0320 nsp RM73B--334JT +2125
R0321 nsp RM73B--473JT +1608
R0322-0325 nsp RS14B3DR47JNBST(S)
R0326-0328 nsp RM73B--103JT +1608

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
