Denon AVR-4520 Service Manual

272
NETWORK/DSP PWB ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
D0601-0603 251310004507S CG0603MLC-12LE
D0701-0716 251310004507S CG0603MLC-12LE
D0802 00D2760683930 UDZS5.1B-TE17 +C
D0803-0805 251310004507S CG0603MLC-12LE
Q0601,0602 21535001250AS KRA302E-RTK/P
Q0603-0606 00MBA2000399Y KRC402E-RTK KEC
Q0701 00D2720166905 2SB798(DL/DK)-T1 +C
Q0802 00MBA2000199Y KRC404E-RTK KEC STANDARD
Q0803 211850008504S 2SA2018TL
Q0804 00D2750110905 HN1K02FU-TE85L
Q0805 21535001250AS KRA302E-RTK/P
U0002 231810089509S EX3AV
U0101 24581002961AS ADSP21487KSWZ4B3027
U0102 24681007360AS A3V56S40FTP-6G
U0103 8R2481011300S
DSP1 ROM SUB ASSY
(MX29LV160DBTI-70G)
U0201 24581002961AS ADSP21487KSWZ4B3027
U0202 24681007360AS A3V56S40FTP-6G
U0203 8R2481011400S
DSP2 ROM SUB ASSY
(MX29LV160DBTI-70G)
U0301 24581002961AS ADSP21487KSWZ4B3027
U0302 24681007360AS A3V56S40FTP-6G
U0303 8R2481011500S
DSP3 ROM SUB ASSY
(MX29LV160DBTI-70G)
U0503 23681011260AS DM860A
U0504 8R2481014100S
DM860 ROM SUB AVR18/21/23/3313_AVR4520
(H27U1G8F2BTR-BC)
U0505,0506 24681007660AS A3V56S30FTP-6G
U0601 236810071503S NLAS7222CMUTBG
U0603,0604 23681012650AS NCP380HMU21AATBG
U0605 00MHC007805KZ TC74VHCT125AFT OUAD BUS BUFFER
U0606 00D2623444902 TC74VHC08FT
U0607 00D2623711907 SAA7121H/V2.518
U0608,0609 231810089509S EX3AV
U0610 23671011050AS
MFI337S3959 IPOD COPROCESSOR 2.0C
CLASS6
U0701 103810002508S PULSE-TRANS (S558-5999-U-7-F)
f
U0702 23681012560AS IP175C LF
U0704 103810002508S PULSE-TRANS (S558-5999-U-7-F)
f
U0705 231810089509S EX3AV
U0706 23681012350AS LAN8720A-CP-TR
U0800 00D2623425905 LTC4300-2CMS8
U0802 23681013060AS SII1292CNUC
RESISTORS GROUP
R0001
nsp RM73B--0R0KT+1005
R0002 nsp RM73B--473JT+1005
R0009-0011 00D2472038925 RM73B--154DT(1608)
R0102 nsp RM73B--103JT +1005
R0103 126210002538S MNR04=330(1005X4)
R0105 nsp RM73B--102JT
R0107-0110 nsp RM73B--472JT+1005
R0111 126210007557S MNR04=472(1005X4)
R0112,0113 126210001511S MNR04=100(1005X4)
R0114 nsp RM73B--560JT
R0115,0116 126210001511S MNR04=100(1005X4)
R0117 126210002538S MNR04=330(1005X4)
R0118 126210007557S MNR04=472(1005X4)
R0119 126210002538S MNR04=330(1005X4)
R0120 nsp RM73B--330JT +1005
R0121-0124 126210002538S MNR04=330(1005X4)
R0125 nsp RM73B--330JT +1005
R0127 nsp RM73B--105JT +1608
R0128 nsp RM73B--470JT +1608
R0129,0130 126210002538S MNR04=330(1005X4)

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
