Denon AVR-4520 Service Manual

273
Ref. No. Part No. Part Name Remarks Q'ty New
R0131-0134 nsp RM73B--330JT +1005
R0135 126210002538S MNR04=330(1005X4)
R0136 nsp RM73B--0R0KT+1005
R0137-0139 126210008536S MNR04=103(1005X4)
R0140 nsp RM73B--472JT+1005
R0142 126210008536S MNR04=103(1005X4)
R0143,0144 126210007557S MNR04=472(1005X4)
R0202 nsp RM73B--103JT +1005
R0203 126210002538S MNR04=330(1005X4)
R0205 nsp RM73B--102JT
R0207-0210 00D2473010900 RM73B--472JT+1005
R0211 126210007557S MNR04=472(1005X4)
R0212,0213 126210001511S MNR04=100(1005X4)
R0214 nsp RM73B--560JT
R0215,0216 126210001511S MNR04=100(1005X4)
R0217 126210002538S MNR04=330(1005X4)
R0218 126210007557S MNR04=472(1005X4)
R0219 126210002538S MNR04=330(1005X4)
R0220 nsp RM73B--330JT +1005
R0221-0224 126210002538S MNR04=330(1005X4)
R0225 nsp RM73B--330JT +1005
R0227 nsp RM73B--105JT +1608
R0228 nsp RM73B--470JT +1608
R0229,0230 126210002538S MNR04=330(1005X4)
R0231-0234 nsp RM73B--330JT +1005
R0235 126210002538S MNR04=330(1005X4)
R0236 nsp RM73B--0R0KT+1005
R0237-0239 126210008536S MNR04=103(1005X4)
R0240 nsp RM73B--472JT+1005
R0243,0244 126210007557S MNR04=472(1005X4)
R0302 nsp RM73B--103JT +1005
R0303 126210002538S MNR04=330(1005X4)
R0305 nsp RM73B--102JT
R0307-0310 nsp RM73B--472JT+1005
R0311 126210007557S MNR04=472(1005X4)
R0312,0313 126210001511S MNR04=100(1005X4)
R0314 nsp RM73B--560JT
R0315,0316 126210001511S MNR04=100(1005X4)
R0317 126210002538S MNR04=330(1005X4)
R0318 126210007557S MNR04=472(1005X4)
R0319 126210002538S MNR04=330(1005X4)
R0320 nsp RM73B--330JT +1005
R0321-0324 126210002538S
MNR04=330(1005X4)
R0325 nsp RM73B--330JT +1005
R0327 nsp RM73B--105JT +1608
R0328 nsp RM73B--470JT +1608
R0329,0330 126210002538S MNR04=330(1005X4)
R0333,0334 nsp RM73B--330JT +1005
R0335,0336 126210002538S MNR04=330(1005X4)
R0337,0338 126210008536S MNR04=103(1005X4)
R0340 nsp RM73B--472JT+1005
R0342 126210008536S MNR04=103(1005X4)
R0343,0344 126210007557S MNR04=472(1005X4)
R0507 nsp RM73B--0R0KT +1608
R0510,0511 126210002538S MNR04=330(1005X4)
R0512,0513 126210008536S MNR04=103(1005X4)
R0515 126210002538S MNR04=330(1005X4)
R0516,0517 nsp RM73B--330JT +1005
R0518 nsp RM73B--103JT +1005
R0519 126210008536S MNR04=103(1005X4)
R0520 nsp RM73B--103JT +1005
R0521 nsp RM73B--330JT +1005
R0522-0524 nsp RM73B--103JT +1005
R0525 nsp RM73B--102JT +1608
R0526 nsp RM73B--103JT +1005
R0527 00D2472035973 RM73B--302DT(1608)
R0529 00D2472042924 RM73B--133DT(1608)

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
