Denon AVR-4520 Service Manual

252
DIGITAL PWB ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
D1113 00D2760750902 RB521S-30TE61 +REF
D1429-1431 00D2760794900 KDS160-RTK/P
D1701 00D2760794900 KDS160-RTK/P
D1702,1703 201310001503S KDS160E
D1704 00D2760794900 KDS160-RTK/P
D1705-1708 201310001503S
KDS160E
D1712 00D2760846900 RB060M-30
D1901-1903 00D2760794900 KDS160-RTK/P
Q0101 213850009503S 2SC4617EBTLR
Q1103-1105 00MBA2000399Y KRC402E-RTK KEC
Q1106,1107 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1108 00D2750110905 HN1K02FU-TE85L
Q1401-1404 00D2710312905 KTA1504S-GR-RTK/P
Q1405,1406 213850009503S 2SC4617EBTLR
Q1407 00D2740195901 2SD2114KT196 +C
Q1409 00D2750110905 HN1K02FU-TE85L
Q1701 00MBA2000199Y KRC404E-RTK KEC STANDARD
Q1702,1703 21535001250AS KRA302E-RTK/P
Q1704 00MBA2000199Y KRC404E-RTK KEC STANDARD
Q1705,1706 21535001250AS KRA302E-RTK/P
Q1707 00MBA2000199Y KRC404E-RTK KEC STANDARD
Q1708-1710 21535001250AS KRA302E-RTK/P
Q1711 00MBA2000399Y KRC402E-RTK KEC
Q1712 00MBA2000199Y KRC404E-RTK KEC STANDARD
Q1713,1714 21535001250AS KRA302E-RTK/P
Q1715 00MBA2000199Y KRC404E-RTK KEC STANDARD
Q1716,1717 21535001250AS KRA302E-RTK/P
Q1718 211850008504S 2SA2018TL
Q1719 00MBA2000199Y KRC404E-RTK KEC STANDARD
Q1720 211850008504S 2SA2018TL
Q1721,1722 00MBA2000199Y KRC404E-RTK KEC STANDARD
Q1723 00D2757001907 FDC608PZ
Q1724 00MBA2000199Y KRC404E-RTK KEC STANDARD
Q1725 211850008504S 2SA2018TL
Q1726 21535001250AS KRA302E-RTK/P
Q1727 00MBA2000199Y KRC404E-RTK KEC STANDARD
Q1901,1902 00MBA2000399Y KRC402E-RTK KEC
Q1903 211850008504S 2SA2018TL
Q1906 213850009503S 2SC4617EBTLR
Q1907 00MBA2000199Y KRC404E-RTK KEC STANDARD
Q1908 211850008504S 2SA2018TL
Q1909 00D2757001907 FDC608PZ
Q1910 00MBA2000399Y KRC402E-RTK KEC
Q2006,2007 00D2690192902 KRC102S-RTK/P (10K-10K)
Q2101,2102 213850009503S 2SC4617EBTLR
Q2103 00MBA2000399Y KRC402E-RTK KEC
Q2104 21535001250AS KRA302E-RTK/P
Q2105,2106 00MBA2000399Y KRC402E-RTK KEC
U0101,0102 262010006704S JSR1165
U0103,0104 00D2623449004 LC89057W-VF4A
U0106 23681012050AS PCM5100PWR
U0108 00D2623077900 TC74VHCU04FT +REF
U0141 236810086505S AK5358BET
U0142 00D2631047906 NJM2115M-TE1 +C
U0301 23681011960AS 5M570ZF256C5N
U0302 231810017504S TK73318WTL-G
U0303 236810083506S CS2100-10-CZZR
U0304 236810012504S FCXO-05B(24.576MHz)
U0305 141810003503S FCXO-05 (30.00MHz)
U0401 231310009508S PQ033DNA1ZPH
U0403-0409 236810081500S PCM1795
U0410-0419 235810050503S NJM4565M
U0421-0430 235810050503S NJM4565M
U1001 23681012860AS SII9575CTUC

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
