Denon AVR-4520 Service Manual

253
Ref. No. Part No. Part Name Remarks Q'ty New
U1101 23381000450AS
TC74VHC4051AFT
U1102 23681012760AS ADV7850KBCZ-5
U1103 00D2623436907 TC74VHC244FT
U1104 231810017504S TK73318WTL-G
U1351 23981007960AS K4T51163QJ-BCE7
U1401 23681012960AS ADV8003-1
U1404 8R2481014500S
GUI ROM SUB ASSY(AVR4520E3/E2/JP)
(MX25L12835EMI-10G)
E3,E2,JP
U1404 8R2481014501S
GUI ROM SUB ASSY(AVR4520E1C)
(MX25L12835EMI-10G)
E1C
U1601,1602 23981007960AS
K4T51163QJ-BCE7
U1701-1703 231810089509S EX3AV
U1705 231810089509S EX3AV
U1707 23681013550AS NCP380HMUAJAATBG
U1708 231810089509S EX3AV
U1709 231810071508S PQ012ENB1ZPH
U1901 231810089509S EX3AV
U1902 00D2623436907 TC74VHC244FT
U1903 23171011750AS NJM2845DL1-33
U1904 23981007450AS PST8448(SC-82AB)
U1905 231310009508S PQ033DNA1ZPH
U2001 8R2431009400S MAIN CPU SUB ASSY (R5F56108VNFP)
U2002 24681007550AS R1EX24256BSAS0A
U2101 8R2431009500S SUB CPU SUB ASSY (R5F3650NNFB)
U2104 00D2623436907 TC74VHC244FT
RESISTORS GROUP
R0103,0104 nsp
RM73B--330JT +1005
R0105,0106 nsp RM73B--750JT
R0109,0110 nsp RM73B--471JT
R0115,0116 nsp RM73B--473JT+1005
R0117,0118 nsp RM73B--334JT +1005
R0121,0122 nsp RM73B--330JT +1005
R0123 nsp RM73B--104JT
R0124 nsp RM73B--680JT
R0125 nsp RM73B--471JT
R0126 nsp RM73B--182JT
R0127 nsp RM73B--392JT +1005
R0128 nsp RM73B--222JT
R0129 nsp RM73B--330JT +1005
R0130 nsp RM73B--332JT
R0131 nsp RM73B--102JT
R0132 nsp RM73B--330JT +1005
R0133 nsp RM73B--221JT +1005
R0134 nsp RM73B--330JT +1005
R0136 nsp RM73B--102JT
R0137 nsp RM73B--0R0KT+1005
R0138 nsp RM73B--221JT +1005
R0139 nsp RM73B--102JT
R0140 nsp RM73B--471JT
R0141 nsp RM73B--330JT +1005
R0144-0146 nsp RM73B--101JT +1608
R0147,0148 nsp RM73B--332JT +1608
R0149 nsp RM73B--101JT +1608
R0150 nsp RM73B--472JT (1608) +1608
R0151,0152 nsp RM73B--683JT +1608
R0153 nsp RM73B--472JT (1608) +1608
R0154,0155 nsp RM73B--474JT +1608
R0168,0169 nsp RM73B--103JT +1005
R0171 nsp RM73B--103JT +1005
R0174,0175 nsp RM73B--471JT +1608
R0178 nsp RM73B--0R0KT+1005
R0188 126210008536S MNR04=103(1005X4)
R0189,0190 126210002538S MNR04=330(1005X4)
R0191 126210008536S MNR04=103(1005X4)
R0192 126210002538S MNR04=330(1005X4)
R0301 126250001502S PRB3T4=0R0(1005X4)

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
