Denon AVR-4520 Service Manual

254
Ref. No. Part No. Part Name Remarks Q'ty New
R0302 126210003555S
MNR04=101(1005X4)
R0304 126250001502S PRB3T4=0R0(1005X4)
R0305,0306 126210002538S MNR04=330(1005X4)
R0307-0313 nsp RM73B--330JT +1005
R0314-0323 126210003555S MNR04=101(1005X4)
R0324,0325 nsp RM73B--330JT +1005
R0326-0329 126210003555S MNR04=101(1005X4)
R0330,0331 nsp RM73B--330JT +1005
R0332-0334 126210003555S MNR04=101(1005X4)
R0335 nsp RM73B--330JT +1005
R0337-0340 nsp RM73B--101JT+1005
R0341 nsp RM73B--102JT
R0342,0343 nsp RM73B--103JT +1005
R0344-0346 nsp RM73B--330JT +1005
R0348 nsp RM73B--103JT +1005
R0351 nsp RM73B--103JT +1005
R0353 nsp RM73B--103JT +1005
R0354 nsp RM73B--330JT +1005
R0355 nsp RM73B--103JT +1005
R0356-0359 nsp RM73B--0R0KT+1005
R0360 nsp RM73B--330JT +1005
R0361 nsp RM73B--103JT +1005
R0362 126210002538S MNR04=330(1005X4)
R0367-0370 nsp RM73B--330JT +1005
R0401 nsp RM73B--0R0KT +2125
R0403 nsp RM73B--102JT
R0404,0405 nsp RM73B--103JT +1608
R0406 nsp RM73B--102JT
R0407,0408 nsp RM73B--103JT +1608
R0409 nsp RM73B--102JT
R0410,0411 nsp RM73B--103JT +1608
R0412 nsp RM73B--102JT
R0413,0414 nsp RM73B--103JT +1608
R0415 nsp RM73B--102JT
R0416,0417 nsp RM73B--103JT +1608
R0418 nsp RM73B--102JT
R0419,0420 nsp RM73B--103JT +1608
R0421 nsp RM73B--102JT
R0422,0423 nsp RM73B--103JT +1608
R0424-0435 nsp RM73B--821JT +2125
R0436,0437 nsp RM73B--152JT +2125
R0438-0441 nsp RM73B--122JT +2125
R0443,0444 nsp RM73B--152JT +2125
R0446,0447 nsp RM73B--101JT +2125
R0448,0449 nsp RM73B--821JT +2125
R0450,0451 nsp RM73B--821JT +1608
R0452-0459 nsp RM73B--821JT +2125
R0460 nsp RM73B--152JT +2125
R0461 nsp RM73B--272JT +2125
R0462-0465 nsp RM73B--122JT +2125
R0467 nsp RM73B--152JT +2125
R0468 nsp RM73B--272JT +2125
R0470,0471 nsp RM73B--101JT +2125
R0472-0483 nsp RM73B--821JT +2125
R0484,0485 nsp RM73B--222JT +2125
R0486-0489 nsp RM73B--122JT +2125
R0490 nsp RM73B--393JT +2125
R0491,0492 nsp RM73B--222JT +2125
R0493 nsp RM73B--393JT +2125
R0494,0495 nsp RM73B--101JT +2125
R0496,0497 nsp RM73B--821JT +1608
R0500,0501 nsp RM73B--821JT +1608
R0504,0505 nsp RM73B--821JT +1608
R0508 nsp RM73B--272JT +1608
R0510,0511 nsp RM73B--122JT +1608
R0515 nsp RM73B--272JT +1608
R0518 nsp RM73B--101JT +1608

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
