Denon AVR-4520 Service Manual

238
PARTS LIST OF P.W.B. UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe modelE1C : China model E1C : China model
JP : Japan model
SPK/SMPS PWB ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
D6001,6002 20305003100AS D15XBN20
D6003-6011 00D2760794900 KDS160-RTK/P
D6012 00D2760683943 UDZS3.6B-TE17
D6013-6022 00D2760794900 KDS160-RTK/P
D6023 00D2760683943 UDZS3.6B-TE17
D6024,6025 00D2760794900 KDS160-RTK/P
D6501,6502 203050021504S 1N4007
D6503 203010001007S D3SB60
D6507 00D2760683901 UDZS5.6B-TE17 +C E3
D6507 00D2760683972 UDZS13B-TE17 +C E2,E1C
D6507 00D2760683930 UDZS5.1B-TE17 +C JP
D6508 20205002710AS P6KE120A(PANJIT) E3,JP
D6509 20305002730AS 1N4003(HOMI)
D6510 00D2760848908 UDZS22B-TE17
D6511 20205004900AS ZENER DIODE 39V_ZJ39B 1/2W
D6512 20205004710AS P6KE150A(PANJIT)
D6513 203050021504S 1N4007
D6514 20305002730AS 1N4003(HOMI)
D6515,6516 20305003200AS SR3060PT
D6517 20105001130AS 1SS133(HOMI)
D6518 212050010508S KIA2431AP
D6519 20205004800AS ZENER DIODE 5.6V_ZJ5.6B 1/2W
D6522 20205004900AS ZENER DIODE 39V_ZJ39B 1/2W
D6801 26301006510AS BL-BJEGJ204L
D6802 00D2760798948 UDZS8.2B-TE17
D6803 263010032409S SIR-341STA49
D6805 20305002730AS 1N4003(HOMI)
D6806,6807 00D2760798935 UDZS20B-TE17
Q6001-6004 00D2730464901 KTC3875S-GR-RTK/P
Q6005 00D2710318909 2N5401S-RTK/P
Q6006-6014 00D2730464901 KTC3875S-GR-RTK/P
Q6015 00D2710312905 KTA1504S-GR-RTK/P
Q6016,6017 00D2730464901 KTC3875S-GR-RTK/P
Q6018 00D2710312905 KTA1504S-GR-RTK/P
Q6019,6020 00D2730464901 KTC3875S-GR-RTK/P
Q6021 00D2710312905 KTA1504S-GR-RTK/P
Q6022 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6023 21585001550AS KRA105S-RTK/P(2.2K-47K)
Q6024-6026 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6027,6028 00D2690184907 KRA102S-RTK/P (10K-10K)
Q6029 21585001550AS KRA105S-RTK/P(2.2K-47K)
Q6030-6032 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6033 21585001550AS KRA105S-RTK/P(2.2K-47K)
Q6034,6035 00D2690184907 KRA102S-RTK/P (10K-10K)
Q6036 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6037,6038 00D2730464901 KTC3875S-GR-RTK/P
Q6039 21585001550AS KRA105S-RTK/P(2.2K-47K)
Q6040,6041 21385001950AS 2SC5810
Q6042 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6043 21585001550AS KRA105S-RTK/P(2.2K-47K)
Q6044 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6045 21585001550AS KRA105S-RTK/P(2.2K-47K)
Q6046 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6047 21585001550AS KRA105S-RTK/P(2.2K-47K)
Q6048 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6049 21585001550AS KRA105S-RTK/P(2.2K-47K)

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
