Denon AVR-4520 Service Manual

239
Ref. No. Part No. Part Name Remarks Q'ty New
Q6050 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6051 21585001550AS KRA105S-RTK/P(2.2K-47K)
Q6052 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6053 21585001550AS KRA105S-RTK/P(2.2K-47K)
Q6054 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6055 21585001550AS KRA105S-RTK/P(2.2K-47K)
Q6501 22985001050AS SSM3K7002BF
Q6502 00D2730464901 KTC3875S-GR-RTK/P
Q6801 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6802,6803 00D2690184907 KRA102S-RTK/P (10K-10K)
Q6804 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6805 00D2690191903 KRA104S-RTK/P (47K-47K)
Q6806 21385001950AS 2SC5810
Q6807 00D2730464901 KTC3875S-GR-RTK/P
U3006 00D2631288901 PQ050DNA1ZPH E2,E1C,JP
U6001 235810050503S NJM4565M
z
U6501 00D2623047008 PC123Y22
z
U6502 23901007520AS TOP256YN
U6801 262010009000S R34FS8A
RESISTORS GROUP
R3121-3124 nsp RM73B--330JT +1608 E2,E1C,JP
R3125 nsp RM73B--222JT +1608 E2,E1C,JP
R3126,3127 nsp RM73B--104JT +1608 E2,E1C,JP
R3128,3129 nsp RM73B--102JT +1608 E2,E1C,JP
R3130,3131 nsp RM73B--104JT +1608 E2,E1C,JP
R3132,3133 nsp RM73B--823JT +1608 E2,E1C,JP
R6001,6002 nsp RM73B--683JT +1608
R6003,6004 nsp RM73B--223JT +1608
R6005,6006 nsp RM73B--0R0KT +1608
R6007,6008 nsp RM73B--124JT +1608
R6009,6010 nsp RM73B--0R0KT +1608
R6011 00MGG0510116X 100 OHM +- 5% 1/6W
R6012,6013 nsp RM73B--124JT +1608
R6014,6015 nsp RM73B--0R0KT +1608
R6016 00MGG0504716X 4.7 OHM +- 5% 1/6W
R6017 nsp RM73B--0R0KT +1608
R6018,6019 nsp RM73B--103JT +1608
R6020 nsp RM73B--122JT +1608
R6021 nsp RM73B--223JT +1608
R6022 nsp RM73B--153JT +1608
R6023-6029
nsp RM73B--103JT +1608
R6030,6031 nsp RM73B--223JT +1608
R6032 nsp RM73B--104JT +1608
R6033-6037 nsp RM73B--223JT +1608
R6038 nsp RM73B--153JT +1608
R6039 nsp RM73B--223JT +1608
R6040 nsp RM73B--104JT +1608
R6041-6049 nsp RM73B--474JT +1608
R6050 nsp RM73B--153JT +1608
R6055 nsp RM73B--104JT +1608
R6060 12905006810AS RGC502T02
R6061 nsp RM73B--103JT +1608
R6062 nsp RM73B--101JT +1608
R6063 nsp RM73B--220JT +2125
R6064 nsp RM73B--102JT +1608
R6065 nsp RM73B--220JT +2125
R6066 nsp RM73B--102JT +1608
R6067 nsp RM73B--220JT +2125
R6068,6069 nsp RM73B--393JT +1608
R6070 nsp RM73B--220JT +2125
R6071,6072 nsp RM73B--473JT +1608
R6073-6075 nsp RM73B--220JT +2125
R6077,6078 nsp RM73B--220JT +2125
R6079 nsp RM73B--333JT +1608
R6080 nsp RM73B--220JT +2125
R6081,6082 nsp RM73B--103JT +2125

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
