Denon AVR-4520 Service Manual

240
Ref. No. Part No. Part Name Remarks Q'ty New
R6083,6084 nsp RM73B--103JT +1608
R6085 nsp RM73B--220JT +2125
R6087 nsp RM73B--332JT +1608
R6088 nsp RM73B--334JT +1608
R6089,6090 nsp RM73B--103JT +1608
R6091 nsp RM73B--102JT +1608
R6092 nsp RM73B--333JT +1608
R6501-6503 nsp RD14B2E225JT(5)
R6504-6506 nsp RD14B2E105JT(5)
R6507 nsp RD14B2E334JT(5)
R6508 nsp RM73B--105JT +1608
R6509 nsp RM73B--102JT +1608
R6510 nsp RM73B--822JT +1608
R6511,6512 nsp RD14B2E225JT(5) E3,JP
R6513 nsp RD14B2E105JT(5) E3,JP
R6514 nsp RM73B--274JT +1608 E3,JP
R6514 nsp RM73B--563JT +1608 E2,E1C
R6516 nsp RD14B2E6R8JT(5)
R6519 nsp RM73B--103JT +1608
R6520 nsp RM73B--102JT +1608
R6522 nsp RD14B2E560JT(5)
R6523 nsp RM73B--332JT +1608
R6524 nsp RM73B--562JT +1608
R6525 nsp RM73B--223DT(1608)
R6526 nsp RD14B2E105JT(5)
R6527 nsp RM73B--682DT(1608)
R6801,6802 nsp RM73B--102JT +1608
R6803,6804 nsp RM73B--471JT +1608
R6807 nsp RM73B--102JT +1608
R6808 nsp RM73B--472JT (1608) +1608
R6809 nsp RM73B--820JT +1608
R6810 nsp RM73B--472JT (1608) +1608
R6811 nsp RM73B--101JT +1608
R6812 nsp RM73B--820JT +1608
R6813,6814 nsp RM73B--101JT +1608
R6815,6816 nsp RM73B--221JT +1608
R6818 nsp RM73B--101JT +1608
R6819 nsp RM73B--473JT +1608
R6820 nsp RM73B--1R8KT
R6821 nsp RM73B--1R5KT
R6823 nsp RM73B--101JT +1608
R6824,6825
nsp RM73B--472JT (1608) +1608
R6826-6828 nsp RM73B--271JT +1608
R6829 nsp RM73B--473JT +2125
R6830-6832 nsp RM73B--221JT +1608
R6833,6834 nsp RM73B--331JT (1608) +1608
R6835 nsp RM73B--561JT +1608
R6836 nsp RM73B--393JT +1608
R6837 nsp RM73B--103JT +1608
R6838 nsp RM73B--101JT +1608
R6839 nsp RM73B--331JT (1608) +1608
R6840,6841 nsp RM73B--100JT +2125
R6842 nsp RM73B--820JT +1608
R6843 nsp RM73B--243JT +1608
R6844 nsp RM73B--0R0KT +1608
R6845 nsp RM73B--102JT +1608
R6846,6847 nsp RM73B--0R0KT +1608
R6851,6852 nsp RM73B--472JT (1608) +1608
CAPACITORS GROUP
C3123 nsp CC73CH1H101JT +1608 E2,E1C,JP
C3126-3129 nsp CC73CH1H101JT +1608 E2,E1C,JP
C3133-3135 13405014840AS CE04W1J100MT(KR3) E2,E1C,JP
C3137 13405014840AS CE04W1J100MT(KR3) E2,E1C,JP
C6001 133050084507S CQ93M2E104KT
C6002,6003 13405018740AS CE04W2A221MT(KR3)
C6004,6005 13405014840AS CE04W1J100MT(KR3)

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
