Denon AVR-4520 Service Manual

241
Ref. No. Part No. Part Name Remarks Q'ty New
C6006 13405012940AS CE04W1C101MT(KR3)
C6007 13405012740AS CE04W1A331MT(KR3)
C6008 nsp CK73B1E104KT +1608
C6009 13405012740AS CE04W1A331MT(KR3)
C6010 nsp CK73B1E104KT +1608
C6011,6012 13405018100AS CE68W==223MDL
C6013 13405012740AS CE04W1A331MT(KR3)
C6016 nsp CK73B1E104KT +1608
C6017 00MDK9610430Y C1608X7R1H104K
C6018 13405014840AS CE04W1J100MT(KR3)
C6019-6022 nsp CK73B1E104KT +1608
C6023,6024 13405018640AS CE04W2A010MT(KR3)
C6025 13405012940AS CE04W1C101MT(KR3)
C6027 13405018640AS CE04W2A010MT(KR3)
C6028 00D2570043919 CK73U2J2E222JT(2125)
C6029-6038 nsp CK73B1H102KT +1608
C6039,6040 00D2570043919 CK73U2J2E222JT(2125)
C6041 nsp CK73B1H102KT +1608
C6042-6049 00D2570043919 CK73U2J2E222JT(2125)
C6050 133050090557S CQ93P2A104JT(PPF)
z
C6501,6502 00D2538029713 CK45F2EAC471KC(KX)
z
C6503 00D2538022707 CK45F2EAC103MC
z
C6504,6505 00D2568039003 CF99--2EAC104K(LEMX)
C6509 nsp CK73B1E473KT +1608 E2,E1C
C6510 nsp CK73B1E104KT +1608
z
C6511,6512 00D2538022707 CK45F2EAC103MC
C6513 13405021210AS CE04W2G121MC(KXG)
C6515 134050107502S CE04W1E470MT(NXA)
C6516 00MDK9610430Y C1608X7R1H104K
C6517 13305015020AS CQ93M3A103H(PHF)
C6519 134050106509S CE04W1H100MT(NXA)
z
C6520 00D2538029700 CK45F2EAC222MC (KX)
C6521 nsp CK73B1E104KT +1608
C6524 00D2570522906 CK73B0J475KT +1608
C6525-6527 134050105209S CE04W0J562MC(NXA)
C6528 nsp CK73B1H102KT +1608
C6529 nsp CK73B1E104KT +1608
C6530 13405012640AS CE04W0J471MT(KR3)
C6801,6802 nsp CK73B1E104KT +1608
C6803 13405014840AS CE04W1J100MT(KR3)
C6804,6805 00MDK9610430Y
C1608X7R1H104K
C6807 13405014940AS CE04W1J101MT(KR3)
C6808,6809 nsp CK73B1E104KT +1608
C6810-6812 00MDK9610430Y C1608X7R1H104K
C6814 00MDK9610430Y C1608X7R1H104K
C6818 nsp CK73B1H102KT +1608
C6820-6822 nsp CK73B1E104KT +1608
C6847,6848 nsp CK73B1E104KT +1608
C6849 13405014440AS CE04W1H101MT(KR3)
OTHERS PARTS GROUP
z
F0010 652050008004S L=30mm 250V TLC15AN4
z
F0020 652050008004S L=30mm 250V TLC15AN4
z
F0050 00D2061086029 FUSE 12A (UL/CSA/J) E3,JP
z
F0050 00D2061091014 FUSE(ET5A) E2,E1C
z
F0070 00MFS20200201 # T2.0A 250V TR5 E3,JP
z
F0070 00MFS20315201 # FUSE 3.15A 250V SEMKO VDE E2,E1C
z
F0080 00MFS20025201 # T250MA/250V TR5 NO.19372(TP)
H0011,0012 nsp FUSE HOLDER(DPS1)
H0021,0022 nsp FUSE HOLDER(DPS1)
H0051,0052 nsp FUSE HOLDER(DPS1) E3,JP
H0061,0062 00D2020040909 FUSE CLIP(TAPE) E2,E1C
K6001 646010030008S 4P SP TERMINAL
K6002 646010030015S 6P SP TERMINAL
K6003-6005 646010030008S 4P SP TERMINAL
L3003 00D2350147909 E.FIL(BLM21PG221SN1)+2125 E2,E1C,JP
z
L6501 11101004400AS L.FILTER(LF2628NP-R273)

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
