Denon AVR-4520 Service Manual

242
Ref. No. Part No. Part Name Remarks Q'ty New
L6505-6508 00D2350049900 BEADS INDUCTOR TAPE
N3006 645010057062S 23P SOCKET(C125Z2) E2,E1C,JP
N4809 645010056069S 23P PLUG(C125Z1)
N6001-6009 00MYP06010450 B5B-EH
N6010 00MYJ06006310 B11B-PH-K-S (LF)(SN)
N6011 00MYJ06006320 B12B-PH-K-S (LF)(SN)
N6012 00MYP06010990 B9P-VH
N6013 00D2050736005 33P FFC BASE
N6501 00MYP04000760 CONNECTOR 2P B3P-VH
N6502 00MYP06010450 B5B-EH
N6801 645010057062S 23P SOCKET(C125Z2)
N6802 645010075008S 40FMN-STRK-A(LF)(SN)
N6803 00MYP06003960 S7B-EH
N9009,9010 00MYP06013300 2P PLUG B2P3S-VH
B6001 61205049500AS 1P 130mm SIN-SIN
B6003 61205010702AD 1P 200mm SIN-SIN
B6005-6007 00MYL01010241 GND TERMINAL FOR PCB
B6501 00D2051034007 M3 SCREW TERMINAL
B6502 00MYL01010241 GND TERMINAL FOR PCB
B6503 00D2051034007 M3 SCREW TERMINAL
z
S6001 68201003000AS RELAY(FTR-F1CL012R)
z
S6002-6011 682010020007S G5PA-28-MC DC12
z
S6501 00D2140241002 RELAY DL1SU TV-8
S6801,6802 663010005007S ROT.ENCODER(EC16B24S0-ZZZ)
S6803-6822 00D2125611903 TACT SWITCH(TAPE H5)
z
T6502 10201002401AS SW TRANS(979C/A)
g
Z3001 18301002800AS TUNER MODULE (KST-MW104FV1-S63V) E2
Z3001 18301002900AS TUNER MODULE (KST-MW004FV1-S63) E1C,JP
Z6001-6003 nsp STYLE PIN
z
Z6502 64105002280AS AC INLET(R-30190)
Z6503,6504 nsp RADIATOR
Z6505 nsp RADIATOR
Z6506 nsp SCREW
Z6513,6514 nsp SCREW
Z6801 17201001300AS FLD(17-BT-40GINK)
Z6802,6803 436010038007D FLD SPACER
Z6804 nsp STYLE PIN
Z6999 nsp CU PLATE(SPK)

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
