Denon AVR-4520 Service Manual

274
Ref. No. Part No. Part Name Remarks Q'ty New
R0530 00D2472041954 RM73B--622DT(1608)
R0531 126210008536S MNR04=103(1005X4)
R0532 nsp RM73B--105JT +1608
R0533 nsp RM73B--152JT
R0534 126210002538S MNR04=330(1005X4)
R0537 nsp RM73B--330JT +1005
R0538,0539 126210002538S MNR04=330(1005X4)
R0540 nsp RM73B--330JT +1005
R0541,0542 nsp RM73B--100JT
R0543 nsp RM73B--272JT
R0544 nsp RM73B--152JT
R0545 126210007557S MNR04=472(1005X4)
R0547-0551 126210002538S MNR04=330(1005X4)
R0552-0555 nsp RM73B--330JT +1005
R0556 nsp RM73B--472JT+1005
R0557 nsp RM73B--330JT +1005
R0558 nsp RM73B--472JT+1005
R0559 nsp RM73B--330JT +1005
R0563,0564 nsp RM73B--472JT+1005
R0565-0568 126210002538S MNR04=330(1005X4)
R0569 nsp RM73B--103JT +1005
R0570 nsp RM73B--330JT +1005
R0601 nsp RM73B--103JT +1608
R0602,0603 nsp RM73B--0R0KT +1608
R0604 nsp RM73B--222JT +1608
R0611 nsp RM73B--103JT +1005
R0612 nsp RM73B--122JT +1005
R0614,0615 nsp RM73B--103JT +1005
R0616 126210009591S MNR04=473(1005X4)
R0617,0618 nsp RM73B--103JT +1005
R0619 126210009591S MNR04=473(1005X4)
R0621 nsp RM73B--103JT +1005
R0622,0623 nsp RM73B--472JT+1005
R0624 nsp RM73B--103JT +1005
R0625,0626 00D2472038925 RM73B--154DT(1608)
R0627 nsp RM73B--155KT +1608
R0628 nsp RM73B--684JT +1608
R0629 00D2472037900 RM73B--473DT(1608)
R0630 00D2472038996 RM73B--304DT(1608)
R0632 nsp RM73B--0R0KT +1608
R0638 nsp RM73B--473JT+1005
R0662,0663 nsp RM73B--0R0KT+1005
R0667 nsp
RM73B--4R7KT
R0668,0669 nsp RM73B--100JT
R0701-0708 nsp RM73B--221JT +1005
R0715-0734 00D2472031977 RM73B--510DT(1608)
R0735 00D2472041954 RM73B--622DT(1608)
R0743 nsp RM73B--105JT +1608
R0744 nsp RM73B--511JT +1608
R0745 nsp RM73B--101JT +1608
R0763 nsp RM73B--472JT+1005
R0765 nsp RM73B--0R0KT+1005
R0767 nsp RM73B--0R0KT+1005
R0768 nsp RM73B--474JT
R0769 nsp RM73B--100JT
R0770 00D2472038925 RM73B--154DT(1608)
R0771 nsp RM73B--684JT +1608
R0772 00D2472037900 RM73B--473DT(1608)
R0774 00D2472041983 RM73B--822DT(1608)
R0776-0778 00D2472031977 RM73B--510DT(1608)
R0779 00D2472041909 RM73B--392DT(1608)
R0780 00D2472031977 RM73B--510DT(1608)
R0781 nsp RM73B--473JT+1005
R0783 nsp RM73B--0R0KT +1608
R0785 nsp RM73B--0R0KT +1608
R0786 nsp RM73B--103JT +1005
R0787 nsp RM73B--152JT

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
