Denon AVR-4520 Service Manual

271
Ref. No. Part No. Part Name Remarks Q'ty New
N3803 645010056069S 23P PLUG(C125Z1)
N3901 00MYP06003950 S5B-EH
N3902 00MYJ06006430 S3B-PH-K-S (LF)(SN)
N3903 00D2051343905 11P FFC BASE(9610SCA
N4001 645010056007S 11P PLUG(C125Z1)
N4002-4007 645010056090S 33P PLUG(C125Z1)
N4008 645010056045S 19P PLUG(C125Z1)
N4009 00MYJ06006240 B4B-PH-K-S (LF)(SN)
N4807 61205053600AS 3P 250mm PH-SAN
f
B3001,3002 nsp M3 SCREW TERMINAL
B3802,3803 nsp M3 SCREW TERMINAL
B3901,3902 nsp M3 SCREW TERMINAL
B3903 nsp M3 SCREW TERMINAL
B4001,4002 nsp M3 SCREW TERMINAL
B4004 nsp M3 SCREW TERMINAL
S3501-3511 682010021000S RELAY(BC3-12)
Z3701 nsp RADIATOR
Z3702 nsp RADIATOR
Z3703-3705 nsp SCREW
Z3706,3707 nsp RADIATOR
Z3708 nsp SCREW
Z3709,3710 nsp STYLE PIN
Z3712-3714 nsp STYLE PIN
Z4004-4006 nsp STYLE PIN

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
