Denon AVR-4520 Service Manual

270
Ref. No. Part No. Part Name Remarks Q'ty New
C3814 13405014840AS CE04W1J100MT(KR3)
C3817-3821 13405014840AS CE04W1J100MT(KR3)
C3823 13405012940AS CE04W1C101MT(KR3)
C3824 nsp CK73B1E104KT +1608
C3825 nsp CC73CH1H101JT +1608
C3832 nsp CK73B1E104KT +1608
C3839 nsp CC73CH1H330JT +1608
C3840-3843 nsp CK73B1E104KT +1608
C3846-3848 13405014840AS CE04W1J100MT(KR3)
C3901,3902 133050090557S CQ93P2A104JT(PPF)
C3903-3906 00D2544761735 CE04W1C472MC(SMQ)
C3909-3912 13405013340AS CE04W1E471MT(KR3)
C3915-3918 nsp CK73B1H102KT +1608
C3919,3920 nsp CK73B1E104KT +1608
C3921 nsp CK73B1H102KT +1608
C3922 nsp CK73B1E104KT +1608
C3923 nsp CK73B1H102KT +1608
C3924,3925 nsp CC73CH1H330JT +1608
C4001-4012 13405014340AS CE04W1H470MT(KR3)
C4017 13405014340AS CE04W1H470MT(KR3)
C4019 13405014340AS CE04W1H470MT(KR3)
C4021 13405014340AS CE04W1H470MT(KR3)
C4024 13405014340AS CE04W1H470MT(KR3)
C4026 13405014340AS CE04W1H470MT(KR3)
C4027,4028 13405013040AS CE04W1E221MT(KR3)
C4031 13405014340AS CE04W1H470MT(KR3)
C4033 13405014340AS CE04W1H470MT(KR3)
C4036 13405014340AS CE04W1H470MT(KR3)
C4038-4040 13405014340AS CE04W1H470MT(KR3)
C4043-4046 nsp RM73B--0R0KT+1005
C4047 nsp CK73B1H102KT +1608
C4048 nsp CC73CH1H101JT +1608
C4049 nsp CK73B1H102KT +1608
C4050 nsp CC73CH1H101JT +1608
C4051-4053 nsp CK73B1H102KT +1608
C4876 nsp CC73CH1H102JT +1608
OTHERS PARTS GROUP
z
F3701 00MFS20250201 # T2.5A/250V TR5 NO.19372 (T
z
F3702 00MFS20200201 # T2.0A 250V TR5
z
F3901,3902 00MFS20315201 # FUSE 3.15A 250V SEMKO VDE
K3102-3104 64301016600AS 6P PIN JACK(RCA-637G)-AU-RW
K3105 64301016700AS 6P PIN JACK(RCA-637G)-AU-RWB
K3301
64301016600AS 6P PIN JACK(RCA-637G)-AU-RW
K3302 64301016800AS 3P PIN JACK(RCA-349BG)-AU-WBB
K3303 64301016600AS 6P PIN JACK(RCA-637G)-AU-RW
K3501,3502 64301017000AS 6P PIN JACK(RCA-637G)-AU-GBR
K3503 64301016900AS 6P PIN JACK(RCA-637G)-AU-Y
K3504 64301017100AS 3P PIN JACK(RCA-349BG)-AU-GBR
K3801 64301017400AS H/P JACK(PJ-612AG-7)-AU
K3802 64301017300AS MINI JACK(MSJ-035)
K3804 00D2048754002 3P PIN JACK(MSP-253V)-AU-B3
K3901,3902 643010086019S MINI JACK(PJ-308-02(RD))
K3903,3904 643010086002S MINI JACK(PJ-308-02)
K3905 64301017200AS 9P D-SUB CONNECTOR(D227FD009S100BY)
K4805 64301000710AS 2PIN PIN JACK(RCA-206BG-00-05)-AU-RD/WH
L3201,3202 00D2359003002 FTZ CHOKE COIL E2,E1C
L3901 00D2350147909 E.FIL(BLM21PG221SN1)+2125
N3001,3002 645010057093S 33P SOCKET(C125Z2)
N3003 00D2050770058 33PFFC BASE (SIDE)
N3004 645010057093S 33P SOCKET(C125Z2)
N3007 645010056069S 23P PLUG(C125Z1) E2,E1C,JP
N3008 00D2051318011 13 FFC BASE(9604F) E3
N3009 61205049900AS 3P 120mm PH-SAN
N3201 00MYJ06006300 B10B-PH-K-S (LF)(SN)
N3202 00MYJ06006280 B8B-PH-K-S (LF)(SN)
N3701 00MYP06010460 B7B-EH

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
