Denon AVR-4520 Service Manual

269
Ref. No. Part No. Part Name Remarks Q'ty New
C3105,3106 nsp CK73B1E104KT +1608 E3
C3107-3110 13405014840AS CE04W1J100MT(KR3) E3
C3112,3113 nsp CC73CH1H330JT +1608 E3
C3115,3116 nsp CC73CH1H330JT +1608 E3
C3117,3118 nsp CK73B1E104KT +1608 E3
C3119,3120 13405014840AS CE04W1J100MT(KR3) E3
C3139 13245005950AS CK73X5R1C106KT(2125) E3
C3201-3212 nsp CC73CH1H331JT +1608
C3213,3214 nsp CC73CH1H471JT +1608
C3215-3222 nsp CC73CH1H331JT +1608
C3225,3226 nsp CC73CH1H221JT +1608
C3227,3228 13405014840AS CE04W1J100MT(KR3)
C3229,3230 13405012440AS CE04W0J221MT(KR3)
C3231,3232 nsp CC73CH1H101JT +1608
C3233,3234 nsp CK73B1E223KT +1608
C3235,3236 nsp CK73B1H682KT +1608
C3237,3238 13405014840AS CE04W1J100MT(KR3)
C3239,3240 13405013240AS CE04W1E470MT(KR3)
C3241-3247 13405012740AS CE04W1A331MT(KR3)
C3248,3249 00D2544577961 CE04W1C331MT(RA3)
C3250-3260 13405012740AS CE04W1A331MT(KR3)
C3261,3262 13405014840AS CE04W1J100MT(KR3)
C3301-3304 nsp CK73X5R1C106KT(2125)
C3305-3312 nsp CK73B1H103KT (1608) +1608
C3313-3316 nsp CK73X5R1C106KT(2125)
C3317-3324 nsp CC73CH1H101JT +1608
C3325-3328 nsp CK73X5R1C106KT(2125)
C3329-3332 nsp CK73B1E104KT +1608
C3333-3336 nsp CK73X5R1C106KT(2125)
C3341,3342 nsp CK73X5R1C106KT(2125)
C3343-3346 nsp CK73B1H332KT +1608
C3347-3350 nsp CK73X5R1C106KT(2125)
C3351-3354 nsp RM73B--0R0KT +2125
C3355-3358 nsp CK73X5R1C106KT(2125)
C3359-3362 nsp CK73B1E104KT +1608
C3519-3537 nsp CE04W1J100MT(KR3)
C3538,3539 nsp CC73CH1H221JT +1608
C3540,3541 nsp CE04W1C101MT(KR3)
C3542-3558 nsp CC73CH1H471JT +1608
C3559 nsp CK73B1E104KT +1608
C3560
nsp CK73B1H102KT +1608
C3702,3703 13405013540AS CE04W1V102MT(KR3)
C3704 133050083511S CQ93M2A104JT(PEF)
C3705-3716 nsp CK73X5R0J106MT(2125)
C3717 13405018320AS CE04W1C472MC(KR1)
C3718 13405018220AS CE04W1C222MC(KR1)
C3719,3720 13405014840AS CE04W1J100MT(KR3)
C3725,3726 13405014840AS CE04W1J100MT(KR3)
C3729-3731 nsp CK73B1E104KT +1608
C3734-3747 nsp CK73B1E104KT +1608
C3748,3749 13405012840AS CE04W1A101MT(KR3)
C3763 133050083511S CQ93M2A104JT(PEF)
C3764 00D2544761735 CE04W1C472MC(SMQ)
C3765 13405014840AS CE04W1J100MT(KR3)
C3766 13405018420AS CE04D1C222MBPC(SME)
C3768 13405018420AS CE04D1C222MBPC(SME)
C3769 13405014840AS CE04W1J100MT(KR3)
C3771 13405014840AS CE04W1J100MT(KR3)
C3773 133050090557S CQ93P2A104JT(PPF)
C3803 nsp CK73B1E104KT +1608
C3804 nsp CK73B1H102KT +1608
C3805 nsp CK73B1E104KT +1608
C3806 nsp CK73B1H102KT +1608
C3807 nsp CK73B1H222KT +1608
C3809 nsp CK73B1H222KT +1608
C3810,3811 nsp CK73B1E104KT +1608
C3812,3813 nsp CC73CH1H331JT +1608

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
