Denon AVR-4520 Service Manual

268
Ref. No. Part No. Part Name Remarks Q'ty New
R3536-3539 nsp RM73B--222JT +1608
R3540-3556 nsp RM73B--104JT +1608
R3557-3573 nsp RM73B--221JT +1608
R3574-3576 nsp RM73B--100JT +1608
R3577-3580 nsp RM73B--101JT +1608
R3701-3712 00D2472032905 RM73B--750DT(1608)
R3713 nsp RM73B--101JT +1608
R3716 nsp RM73B--104JT +1608
R3717 nsp RM73B2B0R0KT +3216
R3725,3726 nsp RM73B--473JT +1608
R3731 00D2472032905 RM73B--750DT(1608)
R3732 nsp RM73B--473JT +1608
R3733 00D2472032905 RM73B--750DT(1608)
R3734,3735 nsp RM73B--472JT (1608) +1608
R3736,3737 nsp RM73B--100JT +1608
R3738,3739 nsp RM73B--101JT +1608
R3740 00D2472032905 RM73B--750DT(1608)
R3741 nsp RM73B--472JT (1608) +1608
R3742 00D2472032905 RM73B--750DT(1608)
R3743,3744 nsp RM73B--100JT +1608
R3745,3746 00D2472032905 RM73B--750DT(1608)
R3747,3748 nsp RM73B--100JT +1608
R3749,3750 00D2472032905 RM73B--750DT(1608)
R3751,3752 nsp RM73B--100JT +1608
R3753-3755 nsp RM73B--102JT +1608
R3762 00D2472032905 RM73B--750DT(1608)
R3805,3806 nsp RM73B--0R0KT +1608
R3808 nsp RM73B--101JT +1608
R3810,3811 nsp RM73B--471JT +1608
R3814 nsp RM73B--333JT +1608
R3815,3816 nsp RM73B--474JT +1608
R3817 nsp RM73B--104JT +1608
R3818 nsp RM73B--683JT +1608
R3820 nsp RM73B--222JT +1608
R3823 nsp RM73B--102JT +1608
R3824-3828 nsp RM73B--103JT +1608
R3829 nsp RM73B--101JT +1608
R3832 nsp RM73B--104JT +1608
R3833,3834 nsp RM73B--103JT +1608
R3837,3838 nsp RM73B--103JT +1608
R3842 nsp RM73B--333JT +1608
R3844-3846 nsp RM73B--101JT +1608
R3849 nsp
RM73B--473JT +1608
R3850,3851 nsp RM73B--103JT +1608
R3870 nsp RM73B--102JT +1608
R3903-3907 nsp RM73B--102JT +1608
R3908 nsp RM73B--472JT (1608) +1608
R3909 nsp RM73B--102JT +1608
R3910 nsp RM73B--472JT (1608) +1608
R3911 nsp RM73B--102JT +1608
R3912 nsp RM73B--332JT +1608
R3913 nsp RM73B--222JT +1608
R3914 nsp RM73B--104JT +1608
R4001-4024 nsp RM73B--103JT +1608
R8062 nsp RM73B--330JT +1005
R8063,8064 nsp RM73B--0R0KT +1608
R8071 nsp RM73B--0R0KT +2125 E3
CAPACITORS GROUP
C0837 nsp CK73B0J475KT +1608
C0838-0843 nsp CK73B1E104KT +1608
C3022-3025 nsp CK73B1E104KT +1608
C3026,3027 nsp CK73X5R0J106MT(2125)
C3028 nsp CK73B1E104KT +1608
C3029-3036 nsp CK73X5R0J106MT(2125)
C3101 nsp CK73B1E104KT +1608 E3
C3102-3104 nsp CC73CH1H101JT +1608 E3

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
