Denon AVR-4520 Service Manual

267
Ref. No. Part No. Part Name Remarks Q'ty New
U3802,3803 235810050503S NJM4565M
RESISTORS GROUP
R0767,0768 nsp RM73B--102JT
R3001-3004 nsp RM73B--0R0KT +1608
R3005-3008 nsp RM73B--750JT +1608
R3026 nsp RM73B--472JT (1608) +1608
R3027,3028 nsp RM73B--0R0KT +1608
R3029,3030 00D2472032905 RM73B--750DT(1608)
R3031-3034 nsp RM73B--0R0KT +1608
R3102 nsp RM73B--0R0KT +1608
R3104 nsp RM73B--100JT +1608 E3
R3106 nsp RM73B--100JT +1608 E3
R3107-3110 nsp RM73B--153JT +1608 E3
R3111-3114 nsp RM73B--393JT +1608 E3
R3115,3116 nsp RM73B--104JT +1608 E3
R3117 nsp RM73B--0R0KT +1608 E3
R3201-3222 nsp RM73B--471JT +1608
R3223-3234 nsp RM73B--824JT +1608
R3235,3236 nsp
RM73B--104JT +1608
R3237-3244 nsp RM73B--824JT +1608
R3245,3246 nsp RM73B--104JT +1608
R3247,3248 nsp RM73B--0R0KT +1608 E3,JP
R3247,3248 nsp RM73B--472JT (1608) +1608 E2,E1C
R3249,3250 nsp RM73B--391JT +1608
R3251,3252 nsp RM73B--683JT +1608
R3253,3254 nsp RM73B--154JT +1608
R3255,3256 nsp RM73B--271JT +1608
R3257,3258 nsp RM73B--470JT +1608
R3259,3260 nsp RM73B--154JT +1608
R3261,3262 nsp RM73B--123JT +1608
R3263,3264 nsp RM73B--470JT +1608
R3265,3266 nsp RM73B--474JT +1608
R3267 nsp RM73B--473JT +1608
R3268,3269 nsp RM73B--0R0KT +1608
R3270-3275 nsp RM73B--470JT +1608
R3276,3277 nsp RM73B--473JT +1608
R3278-3283 nsp RM73B--470JT +1608
R3284-3288 nsp RM73B--473JT +1608
R3289,3290 nsp RM73B--470JT +1608
R3291,3292 nsp RM73B--473JT +1608
R3293,3294 nsp
RM73B--470JT +1608
R3295 nsp RM73B--473JT +1608
R3296,3297 nsp RM73B--470JT +1608
R3298 nsp RM73B--0R0KT +1608
R3301-3304 nsp RM73B--474JT +1608
R3305-3308 nsp RM73B--154JT +1608
R3309-3312 nsp RM73B--334JT +1608
R3313-3316 nsp RM73B--101JT +1608
R3317-3320 nsp RM73B--104JT +1608
R3321-3328 nsp RM73B--393JT +1608
R3329-3332 nsp RM73B--223JT +1608
R3333-3340 nsp RM73B--472JT (1608) +1608
R3341-3344 nsp RM73B--470JT +1608
R3345-3348 nsp RM73B--104JT +1608
R3349-3352 nsp RM73B--101JT +1608
R3353-3356 nsp RM73B--472JT (1608) +1608
R3357-3364 nsp RM73B--104JT +1608
R3371-3377 126210009591S MNR04=473(1005X4)
R3378-3385 126250001502S PRB3T4=0R0(1005X4)
R3386 126210009591S MNR04=473(1005X4)
R3501-3508 nsp RM73B--100JT +1608
R3509-3525 nsp RM73B--104JT +1608
R3526-3529 nsp RM73B--224JT +1608
R3530,3531 nsp RM73B--102JT +1608
R3532,3533 nsp RM73B--222JT +1608
R3534,3535 nsp RM73B--101JT +1608

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
