Denon AVR-4520 Service Manual

189
Ref. No. Part No. Part Name Remarks Q'ty New
U10 nsp ENVELOPE CIBKE3 1
U10 nsp ENVELOPE (ZIPPER A4) K 1
U10 nsp ENVELOPE SPE1C 1
U10 nsp ENVELOPE SPE2 1
U20 35201017700AD INST. MANUAL (E2 CD-ROM) BKE2 1
U20 35201017300AD INST. MANUAL (CD-ROM) CIBKE3 1
U20 35201017900AD INST. MANUAL (JP CD-ROM) K 1
U20 35201017800AD INST. MANUAL (E1C CD-ROM) SPE1C 1
U20 35201017700AD INST. MANUAL (E2 CD-ROM) SPE2 1
U25 35201018600AD INST. MANUAL(E2 CD-ROM) BKE2 1
U25 35201018600AD INST. MANUAL(E2 CD-ROM) SPE2 1
U30 54111094700AD GETTING STARTED (E2) BKE2 1
U30 54111094000AD GETTING STARTED CIBKE3 1
U30 54111094900AD GETTING STARTED (JP) K 1
U30 54111094800AD GETTING STARTED (E1C) SPE1C 1
U30 54111094700AD GETTING STARTED (E2) SPE2 1
U40 nsp S.S.LIST(EX) BKE2 1
U40 nsp S.S.LIST(EX) CIBKE3 1
U40 nsp SERVICE STATION LIST K 1
U40 nsp S.S.LIST(EX) SPE1C 1
U40 nsp S.S.LIST(EX) SPE2 1
U50 nsp GUARANTEE(S)SUB ASSY K 1
U50 nsp WARRANTY FOR CHINA DENON SPE1C 1
U60 11601001400AS AM ANTENNA(ANTA12G) CIBKE3 1
U70 11601001100AS FM ANT ASSY BKE2 1
U70 11601001100AS FM ANT ASSY
CIBKE3 1
U70 11601001100AS FM ANT ASSY K 1
U70 11601001100AS FM ANT ASSY SPE1C 1
U70 11601001100AS FM ANT ASSY SPE2 1
U75 nsp PAD 1
U80 nsp BATTERY(LR6KE2PT) 1
U90 00MZC01803080 # 2P AC CORD 10A 250V CLASS2 BKE2 1
U90 611050024005S AC CORD SET(E3) V CIBKE3 1
U90 61105004200AS OFC AC CORD SET(H20) K 1
U90 00D2062249001 AC CORD (E1C) SPE1C 1
U90 00MZC01803080 # 2P AC CORD 10A 250V CLASS2 SPE2 1
U100 nsp POLY COVER BKE2 1
U100 nsp POLY COVER CIBKE3 1
U100 nsp ENVELOPE K 1
U100 nsp POLY COVER SPE1C 1
U100 nsp POLY COVER SPE2 1
U110 32401000800AD MIC AUDYSSEY ACM1HB 1
U120 30701010600AD RC-1165 1
U125 nsp SERVICE CONTRACT SHEET(E3only) CIBKE3 1
U130 nsp COLOR LABEL SPE1C 1
U130 nsp COLOR LABEL SPE2 1

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
