193
Pin Pin Name Symbol I/O
Pull up/
down
LvCnv STBY STOP
CEC
STBY
Function
83
PB3/A11/PO27/
TIOCC9/TIOCD9
NC O L L L NC
84
PB2/A10/PO26/
TIOCC9
C O L L L NC
85
PB1/A9/PO25/TIOCA9/
TIOCB9
V FANDET I M3VPu I L I NC
86 P74/ADTRG3# V FANCONT ON O L L L NC
87 P73 AEXP OE O L L L EXPANDER control pin(AUDIO MUTE)
88 P72 AEXP CLK O L L L EXPANDER control pin(AUDIO MUTE)
89
P71/CS4#-C/CS5#-C/
CS6#-C/CS7#-C
AEXP DATA O L L L EXPANDER control pin(AUDIO MUTE)
90 P70/CS3#-B/ADTRG2# AEXP STB O L L L EXPANDER control pin(AUDIO MUTE)
91 VCC VCC - - - - +3.3V
92 PB0/A8/PO24/TIOCA9 NC O/I L L L NC
93 VSS VSS - - - - GND
94
PA7/A7/PO23/TIOCA8/
TIOCB8/TCLKH
NC O L L L NC
95 PA6/A6/PO22/TIOCA8 VSEL A I I I I
Master Volume rotation detection pin(Rotary
encoder)
96
PA5/A5/PO21/TIOCA7/
TIOCB7/TCLKG
VSEL B I I I I
Master Volume rotation detection pin(Rotary
encoder)
97
PA4/A4/PO20/TIOCA7 MHL VBUS CONT O L L L MHL VBUS control pin
98
PA3/A3/PO19/TIOCC6/
TIOCD6/TCLKF
DAC(ETHER) MUTE O L L L
DAC MUTE control pin(PCM5100 for
DM860A),MUTE ON="L"
99
PA2/A2/PO18/TIOCC6/
TCLKE
HUB SDA O HUB3VPu L L L HUB control pin
100
PA1/A1/PO17/TIOCA6/
TIOCB6
HUB SCL O HUB3VPu L L L HUB control pin
101
PA0/A0/BC0#/PO16/
TIOCA6
HUB CONTROL O L L L HUB control pin
102 PE7/IRQ7-A/D15 MHL CABLE DET I I I I MHL Cable detection pin
103 PE6/IRQ6-A/D14 (MHL W/U) I I I I (MHL WakeUp detection pin)
104 PE5/IRQ5-A/D13 REQ SOMI I I L I
MAIN-SUB CPU Communication control
output
105 PE4/D12 ISEL A I I I I
Input Selector rotation detection pin(Rotary
encoder)
106 PE3/D11 ISEL B I I I I
Input Selector rotation detection pin(Rotary
encoder)
107 PE2/D10 VOL CLK1 O L L L
FUNCTION / VOLUME control
pin(R2A15220)
108 PE1/D9 VOL DATA O L L L
FUNCTION / VOLUME control
pin(R2A15220)
109 PE0/D8 VOL CLK2 O L L L
FUNCTION / VOLUME control
pin(R2A15220)
110 PD7/D7 (VOL CLK3) O L L L NC
111 PD6/D6 MHL POWER O L L L MHL(Sil1292) power control pin
112 PD5/D5
ASO DET I I I I PROTECTION (ASO) (detect:"L")
113 PD4/D4 DC DET I I I I PROTECTION (ASO) (detect:"L")
114 P64/CS4#-B FANDET_HIGH I/O I/L L/L I/L FAN control detection pin (detect:"L")
115 P63/CS3#-A/CS7#-A FANDET_ON I/O I/L L/L I/L FAN control detection pin (detect:"L")
116 P62/CS2#-A/CS6#-A E SPI CS O N3VPu L L L
ETHERNET communication control pin
(DM860A)
117
P61/CS1#/CS2#-B/
CS5#-A/CS6#-B/
CS7#-B
(FRONT RESET) O L L L Reset for Front HDMI(SiI1292)
118
P60/CS0#/CS4#-A/
CS5#-B
NC O L L L NC
119 PD3/D3 NC O L L L NC
120 PD2/D2 NC O L L L NC
121 PD1/D1 FL CLK O L L L VFD control pin
122 PD0/D0 FL DATA O L L L VFD control pin
123 P97/AN15 CURRENT DET I/O I/L L/L I/L AMP current detection pin
124 P96/AN14 TR DET (THERMAL) I/O I/L L/L I/L TR thermal detection pin
125 P95/AN13 THERMALINA I/O I/L L/L I/L PROTECTION detection pin (detect:"L")
126 P94/AN12 THERMALINB I/O I/L L/L I/L PROTECTION detection pin (detect:"L")
127 P93/AN11 MAIN POWER O L L L MAIN POWER control pin
To Next Page
