Pin No. Mnemonic Type Description
L7 DVDD Power Digital Power Supply (1.8 V).
L8 GND GND Ground.
L9 GND GND Ground.
L10 GND GND Ground.
L11 GND GND Ground.
L12 GND GND Ground.
L13 GND GND Ground.
L14 GND GND Ground.
L15 GND GND Ground.
L16 GND GND Ground.
L17 GND GND Ground.
L20 HPD_TX1 HDMI Tx1 Hot Plug Assert Signal Input for HDMI Tx1.
L21 GND GND Ground.
L22 TX1_C+ HDMI Tx1 HDMI1 Clock True Output.
L23 TX1_C− HDMI Tx1 HDMI1 Clock Complementary Output.
M1 P[28] Digital video input Digital Video Input Bus[35:0].
M2 P[29] Digital video input Digital Video Input Bus[35:0].
M3 P[30] Digital video input Digital Video Input Bus[35:0].
M4 P[31] Digital video input Digital Video Input Bus[35:0].
M7 GND GND Ground.
M8 GND GND Ground.
M9 GND GND Ground.
M10 GND GND Ground.
M11 GND GND Ground.
M12 GND GND Ground.
M13 GND GND Ground.
M14 GND GND Ground.
M15 GND GND Ground.
M16 GND GND Ground.
M17 GND GND Ground.
M20 R_TX1 HDMI Tx1
1
Sets Internal Reference Currents. Place a 470 Ω resistor (1% tolerance) between
this pin and ground. The external resistor should be placed as close as possible
to the ADV8003.
M21 PVDD5 Power
HDMI Tx PLL Power Supply (1.8 V). This pin is a voltage regulator output.
Connect a decoupling capacitor between this pin and ground.
M22 HEAC_1+ HDMI Tx1 HDMI Tx1 HEC+ from HDMI Connector.
M23 HEAC_1− HDMI Tx1 HDMI Tx1 HEC− from HDMI Connector.
N1 P[24] Digital video input Digital Video Input Bus[35:0].
N2 P[25] Digital video input Digital Video Input Bus[35:0].
N3 P[26] Digital video input Digital Video Input Bus[35:0].
N4 P[27] Digital video input Digital Video Input Bus[35:0].
N7 GND GND Ground.
N8 GND GND Ground.
N9 GND GND Ground.
N10 GND GND Ground.
N11 GND GND Ground.
N12 GND GND Ground.
N13 GND GND Ground.
N14 GND GND Ground.
N15 GND GND Ground.
N16 GND GND Ground.
N17 GND GND Ground.
