Denon AVR-4520 Service Manual

276
Ref. No. Part No. Part Name Remarks Q'ty New
C0124 nsp CK73B1A104KT +1005
C0125 nsp CK73B1H102KT +1005
C0126 nsp CK73B1A104KT +1005
C0127,0128 nsp CK73B1H102KT +1005
C0129 nsp CK73B1A104KT +1005
C0130 nsp CK73B1H102KT +1005
C0131,0132 nsp CK73B1A104KT +1005
C0133 nsp CK73B1H102KT +1005
C0134 nsp CK73B1H102KT +1608
C0135 nsp CK73B1A104KT +1005
C0136 nsp CC73CH1H8R0DT +1608
C0137 nsp CK73B1H102KT +1005
C0138 nsp CK73B1A104KT +1005
C0139,0140 nsp CK73B1H102KT +1005
C0141 nsp CC73CH1H8R0DT +1608
C0142 nsp CK73B1A104KT +1005
C0143,0144 nsp CK73B1H102KT +1005
C0145-0147 nsp CK73B1A104KT +1005
C0148 nsp CK73B1H102KT +1005
C0149 nsp CK73B1A104KT +1005
C0150,0151 nsp CK73B1H102KT +1005
C0152 nsp CK73B1A104KT +1005
C0153 nsp CK73B1H102KT +1005
C0154 nsp CK73B1A104KT +1005
C0155 nsp CK73B1H102KT +1005
C0156 nsp CK73B1A104KT +1005
C0157 nsp CK73B1H102KT +1005
C0158,0159 nsp CK73B1A104KT +1005
C0160 nsp CK73B1H102KT +1005
C0161 nsp CK73B1A104KT +1005
C0162 nsp CK73B1H102KT +1005
C0163,0164 nsp CK73B0J475KT +1608
C0167,0168 nsp CK73B0J475KT +1608
C0169-0171 nsp CK73B1H102KT +1005
C0172 nsp CK73B1A104KT +1005
C0173 nsp CK73B1H102KT +1005
C0174 nsp CK73B1A104KT +1005
C0175 nsp CK73B1H102KT +1005
C0176 nsp CK73B1A104KT +1005
C0177 nsp CK73B1H102KT +1005
C0178 nsp CK73B1A104KT +1005
C0179-0181 nsp CK73B1H102KT +1005
C0182 nsp
CK73B1A104KT +1005
C0183 nsp CK73B1H102KT +1005
C0184-0188 nsp CK73B1A104KT +1005
C0189 nsp CK73B1H102KT +1005
C0190 nsp CK73B1A104KT +1005
C0191 nsp CK73B1H102KT +1005
C0192 nsp CK73B1A104KT +1005
C0193 nsp CK73B1H102KT +1005
C0194 nsp CK73B1A104KT +1005
C0195 nsp CK73B1H102KT +1005
C0196 nsp CK73B1A104KT +1005
C0197 nsp CK73B1H102KT +1005
C0198 nsp CK73B1A104KT +1005
C0199-0201 nsp CK73B1H102KT +1005
C0202 nsp CK73B1A104KT +1005
C0203 nsp CK73B1H102KT +1005
C0204 nsp CK73B1A104KT +1005
C0205 nsp CK73B1H102KT +1005
C0206 nsp CK73B1A104KT +1005
C0207 nsp CK73B1H102KT +1005
C0208 nsp CK73B1A104KT +1005
C0209 nsp CK73B1H102KT +1005
C0210 nsp CK73B1A104KT +1005
C0211,0212 nsp CK73B1H102KT +1005
C0213 nsp CK73B1A104KT +1005

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
