Denon AVR-A100 User Manual

75
Basic versionSimple version Information
ENGLISH
Advanced version
Menu map
For menu operation, connect a TV to this unit and display the menu on the TV screen. For menu operations, see the following page.
How to make detailed settings
Setting items Detailed items Description Page
INFORMATION Status Shows information about current settings. 107
Audio Input Signal Shows information about audio input signals. 107
HDMI Information Displays the HDMI input/output signals and HDMI monitor information. 107
Auto Surround Mode Displays the settings stored for the auto surround mode. 107
Quick Select Displays the settings stored for the Quick Select function. 107
Preset Channel Shows information about tuner or network preset channels. 107
SOURCE SELECT
Displayed items of the
“SOURCE SELECT” menu
differs, depending on the
selected input source.
Play Displays the playback screen of each input source. 80
Auto Preset Uses the auto preset function to program radio stations. 81
Preset Skip Sets the preset memories that you do not want to display when tuning. 81
Parental Lock Sets the Parental Lock. 81
Antenna Aiming Adjusts the SIRIUS reception sensitivity. 81
Preset Name Assigns name to a preset memory. 81
Input Assign Changes input connector assignment. 82
Video Makes the video settings. 83
Input Mode Sets the audio input mode and decode mode. 84
Rename Changes the display name for this source. 85
Source Level Adjusts the playback level of the audio input. 85
Playback Mode Makes settings for iPod, USB memory device or network source playback. 85
Still Picture Makes settings for still picture playback. 85
SURROUND MODE Selects a listening mode. 50
AUDIO/VIDEO ADJUST Audio Adjust Adjusts various audio parameters. 86
Picture Adjust Adjusts the picture quality. 92
AUTO SETUP Audyssey Auto Setup Makes the optimum settings for the speakers being used automatically. 7
Parameter Check Checks Audyssey
®
Auto Setup measurement results.
This item is only displayed after Audyssey Auto Setup procedure has been
performed.
12
MANUAL SETUP Speaker Setup Sets the speaker size and distance, the channel level, etc. 93
HDMI Setup Makes settings for HDMI video/audio output. 98
Audio Setup Makes settings for audio playback. 99
Network Setup Makes network settings. 101
Zone Setup Makes settings for audio playback in a multi-zone (ZONE2/ZONE3) system. 103
Option Setup Makes various other settings. 104
Language Set the language for display the menu on the TV screen. 106
Items that only need to be set once
Set these for example upon purchase.
Once these items are set, there is no need to
set them again unless the speaker layout or the
connected speakers have been changed.

Denon AVR-A100 Specifications

General

Impedance	4 Ω
Sensitivity	102 dB
Output level	150 mV
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	9.2 channels
Total Harmonic Distortion (THD)	0.05 %
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	7
Audio (L/R) in	9
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
AirPlay	Yes
Display	-
HDMI version	1.4a
Product color	Black
Audio decoders	DTS-HD, Dolby TrueHD
Handheld remote control	No
Apple docking compatibility	Not supported
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W
Connectivity technology	Wired
Speakers connectivity type	RCA
Audio (L/R) out	11
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	SIRIUS Internet Radio

Weight and Dimensions

Depth	414 mm
Width	434 mm
Height	171 mm
Weight	18500 g
