Denon AVR-A100 User Manual

115
Basic versionSimple version Information
ENGLISH
Advanced version
Operating the sub remote control
unit
• The sub remote control unit is equipped with frequently used
buttons, so it can be used for simple remote control unit operations.
• The sub remote control unit can also be used for multi-zone, so you
can use it to control this unit from other rooms.
• The operations listed below can be performed with the sub remote
control unit.
• Switching the input source
• Adjusting the volume
• SIRIUS, HD Radio and iPod operations
• NET/USB direct play
• Menu operations
• Zone power on/off
• It is not possible to operate devices other than the amplifier.
NOTE
This unit cannot be used in the ZONE4 mode.
DIRECT PLAY button
• Playback is possible in the mode selected at menu “Direct Play”.
FAVORITES
Playback starts from the first track registered in the favorites.
ALL MUSIC
Playback starts from the first track registered in the “Music” folder.
• When
USB is pressed, playback starts from the first track on the
USB memory device.
NOTE
When the media server is stopped or restarted, it may no longer be
possible to play tracks stored in the favorites.
Setting the display time length of the
remote control unit display
Use the following procedure to set the length of time for which to
display data such as zone and mode on the display panel of the remote
control unit.
1
3UHVV DQG KROG POWER ON DQG
ZONE/DEVICE ON IRU DW OHDVW 
VHFRQGV
“SETUP” flashes twice on the remote
control unit.
2
8VH ui WR GLVSOD\ ³/&'´ RQ
WKHUHPRWHFRQWUROXQLWDQGSUHVV
ENTER
3
8VH ui WR VHW WKH GLVSOD\ WLPH
OHQJWKDQGSUHVV
ENTER
“SET” flashes four times on the remote
control unit and the normal operation
mode is restored.
Remote control unit display Display time
05SEC 5 sec
10SEC 10 sec
15SEC 15 sec
30SEC 30 sec
The backlight of the remote control unit lights for 10 sec.
Operating the main remote control unit
Restoring all settings of the remote control
unit to default
Use the following procedure to restore all default settings of the
remote control unit at the time of purchase.
1
3UHVV DQG KROG POWER ON DQG
ZONE/DEVICE ON IRU DW OHDVW 
VHFRQGV
“SETUP” flashes twice on the remote
control unit.
2
8VHuiWRGLVSOD\³5(6(7´RQ
WKHUHPRWHFRQWUROXQLWDQGSUHVV
ENTER
3
8VH ui WR GLVSOD\ ³$//´ RQ
WKHUHPRWHFRQWUROXQLWDQGSUHVV
ENTER
4
8VHuiWRGLVSOD\³<(6´RQ
WKHUHPRWHFRQWUROXQLWDQGSUHVV
ENTER
“RESET” flashes four times on the
remote control unit and the normal
operation mode is restored.

Denon AVR-A100 Specifications

General

Impedance	4 Ω
Sensitivity	102 dB
Output level	150 mV
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	9.2 channels
Total Harmonic Distortion (THD)	0.05 %
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	7
Audio (L/R) in	9
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
AirPlay	Yes
Display	-
HDMI version	1.4a
Product color	Black
Audio decoders	DTS-HD, Dolby TrueHD
Handheld remote control	No
Apple docking compatibility	Not supported
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W
Connectivity technology	Wired
Speakers connectivity type	RCA
Audio (L/R) out	11
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	SIRIUS Internet Radio

Weight and Dimensions

Depth	414 mm
Width	434 mm
Height	171 mm
Weight	18500 g
