Denon AVR-X1100W

Pin Pin Name Symbol I/O Pu/Pd
Lv
Cnv
STBY STOP
CEC
STBY
Function
27
P32/IRQ2-A/PO10/
TIOCC0/TCLKA-A
MN864778A
HINT
I I I I
MN864778A HDMI INT input
28
P31/IRQ1-A/PO9/
TIOCA0/TIOCB0
ADV7623 INT1 I I I I
ADV7623 INT1 output
29
P30/IRQ0-A/PO8/
TIOCA0
RC IN I I I I
RemoteControl Signal input
30
P27/PO7/TIOCA5/
TIOCB5/SCK1
Hi-B RL O L L L
HIGH B RELAY Control
31
P26/PO6/TIOCA5/
TMO1/TxD1
PSCL I/O C
CEC
3VPu
O/L L L
MN864778/778A Control
32
P25/PO5/TIOCA4/
TMCI1/RxD1
PSDA I/O C
CEC
3VPu
O/L L L
MN864778/778A Control
33
P24/PO4/TIOCA4/
TIOCB4/TMRI1
TU RST O SW3VPu L L L
TUNER Control
34
P23/PO3/TIOCC3/
TIOCD3
E RESET
O
(ODR)
N3VPu L L L
ETHERNET RESET Control pin (CY920) ※control
in the NMOS open-drain conguration
35
P22/PO2/TIOCC3/
TMO0/SCK0
E SPI CLK O N3VPu L L L
ETHERNET Communication control pin (CY920)
36
P21/PO1/TIOCA3/
TMCI0/RxD0
E SPI MIEO I N3VPu I L I
ETHERNETCommunication control pin (CY920)
37
P20/PO0/TIOCA3/
TIOCB3/TMRI0/TxD0
E SPI MOEI O N3VPu L L L
ETHERNETCommunication control pin (CY920)
38
P17/IRQ7-B/
TCLKD-B/TxD3/
SCL0/ADTRG1#
TU SCLK O L L L
TUNER Control
39 PLLVCC PLLVCC - - - -
PLL POWER pin
40
P16/IRQ6-B/
TCLKC-B/RxD3/
SDA0
TU SDIO I_O L L L
TUNER Control
41 PLLVSS PLLVSS - - - -
PLL GND pin
42
P15/IRQ5-B/
TCLKB-B/SCK3/
SCL1
EEPROM SCL O M3VPu I I I
EEPROM Control pin
43
P14/IRQ4-B/
TCLKA-B/SDA1
EEPROM SDA I_O M3VPu I I I
EEPROM Control pin
44
P13/IRQ3-B/TxD2/
ADTRG0#
ADV7623 SPI
MO
O L L L
OSD Control pin (ADV7623)
45 P12/IRQ2-B/RxD2
ADV7623 SPI
MI
I L L L
OSD Control pin (ADV7623)
46 P11/IRQ1-B/SCK2
ADV7623 SPI
CLK
O L L L
OSD Control pin (ADV7623)
47 P10/IRQ0-B
ADV7623 SPI
CS
O L L L
OSD Control pin (ADV7623)
48
P37/PO15/TIOCA2/
TIOCB2/TCLKD-A
HSCL (400k) O
CEC
3VPu
L L L
ADV7623 Control
49 P36/PO14/TIOCA2 HSDA (400k) I_O
CEC
3VPu
L L L
ADV7623 Control
50
P35/PO13/TIOCA1/
TIOCB1/TCLKC-A
MN864778 RST O SW3VPu L L L
MN864778 Reset termina
51 P84 CEC_OUT O L L -
CEC-D Signal output terminal
52
P57/WAIT#/
TRDATA3
MN864778A
RST
O SW3VPu L L L
MN864778A Reset termina
53 P56/TRDATA2 E POWER1 O L L L
ETHER POWER Control pin (CY920)(3.3V Control)
54 P55/TRDATA1 ADV7623 RST O SW3VPu L L L
HDMI Tx/Rx/OSD Reset (ADV7623)
55 P54/TRDATA0 E POWER2 O L L L
ETHER POWER Control pin (CY920)(2.5V Control)
56 P83 E POWER3 O L L L
ETHER POWER Control pin (CY920)(1.8V Control)
57 VSS VSS - - - -
GND
58 P82/TRCLK FL CE O L L L
FL Control pin
59 VCC VCC - - - -
POWER pin
60 P81/TRSYNC FL RST O L L L
FL Control pin
61 P80 E POWER4 O L L L
ETHER POWER Control pin (CY920)(1.2V Control)
62
BCLK/P53(
input 専
用）
THERMAL F I Pu I L I
PROTECTION detection pin(Heat Sink)
63 P52/RD# E FACT RST O Pd L L L
ETHERNET Control pin (Factory Reset)(CY920)
64 P51/WR1#/BC1#
DAC(ETHER)
MUTE
O L L L
DAC MUTE Control pin MUTE ON="L"
65 P50/WR0#/WR# THERMAL E I Pu I L I
PROTECTION detection pin(Heat Sink)
66 P77 H5V DET I I I I
HDMI IN 5V detection pin
130
