Denon AVR-X1100W

Pin Pin Name Symbol I/O Pu/Pd
Lv
Cnv
STBY STOP
CEC
STBY
Function
67 P76/IRQ14-A TU GPO2_INT I L L L
TUNER Control
68 P75
ZVOL
MUTE(NA)/
NC(AP/CH)
O L L L
ZONE VOL(BD3812) Control
69
PC7/A23/CS4#-D/
CS7#-D/TxD5
DSP MOSI O DA3VPu L L L
DSP communication (transmission)
70
PC6/A22/CS6#-D/
RxD5
DSP MISO I DA3VPu L L L
DSP communication (reception)
71
PC5/A21/CS5#-D/
SCK5
DSPI CLK O DA3VPu L L L
DSP communication (CLK)
72 PC4/A20 DSP RST O L L L
DSP RESET
73 PC3/A19 DSP FLAG0 I Pd L L L
DSP FLAG0 input
74 VCC VCC - - - -
POWER pin
75 PC2/A18 DSP ICS O DA3VPu L L L
DSP ChipSelect
76 VSS VSS - - - -
GND
77 PC1/A17
WHITE
LED(NA)/
GREEN
LED(AP/CH)
O L L L
POWER LED Control pin (ON:"H")
78 PC0/A16 RED LED O L/H L H
POWER/STANDBY LED Control pin (ON:"H")(De)
79
PB7/A15/PO31/
TIOCA11/TIOCB11
H/P RL O L L L
HEADPHONE RELAY Control
80
PB6/A14/PO30/
TIOCA11
FRONT RL O L L L
SPEAKER RELAY Control
81
PB5/A13/PO29/
TIOCA10/TIOCB10
HUB CONTROL O L L L
870 oint board HUB IC Control
82
PB4/A12/PO28/
TIOCA10
TU_SEN O L L L
TUNER Control
83
PB3/A11/PO27/
TIOCC9/TIOCD9
C/S RL O L L L
SP RELAY Control
84
PB2/A10/PO26/
TIOCC9
SB RL O L L L
RELAY Control
85
PB1/A9/PO25/
TIOCA9/TIOCB9
D5V POWER O L L H
Digital 5V Control pin (5 → 3.3V,1.8V)
86 P74/ADTRG3# DIR CE O L L L
DIR Control pin
87 P73 DIR DIN O L L L
DIR Control pin
88 P72 DIR DOUT I DA3VPu I I I
DIR Control pin
89
P71/CS4#-C/
CS5#-C/CS6#-C/
CS7#-C
DIR CLK O L L L
DIR Control pin
90
P70/CS3#-B/
ADTRG2#
DIR RST O L L L
DIR Control pin
91 VCC VCC - - - -
POWER pin
92
PB0/A8/PO24/
TIOCA9
7623 ROM
HOLD
O L L L
ADV7623 用 SPI FLASH ROM HOLD Control pin
93 VSS VSS - - - -
GND
94
PA7/A7/PO23/
TIOCA8/TIOCB8/
TCLKH
VEXP OE O L L L
VIDEO Control EXPANDER Control pin
95
PA6/A6/PO22/
TIOCA8
VSEL A I I I I
Master Volume Rotation detection input
（ENCODOR）※ Operate as VSEL B
96
PA5/A5/PO21/
TIOCA7/TIOCB7/
TCLKG
VSEL B I I I I
Master Volume Rotation detection input
（ENCODOR）※ Operate as VSEL A
97
PA4/A4/PO20/
TIOCA7
ZVOL
DATA(NA)/
NC(AP/CH)
O L L L
ZONE VOL(BD3812) Control
98
PA3/A3/PO19/
TIOCC6/TIOCD6/
TCLKF
ZVOL CLK(NA)/
NC(AP/CH)
O L L L
ZONE VOL(BD3812) Control
99
PA2/A2/PO18/
TIOCC6/TCLKE
PRE Z2
MUTE(NA)/
NC(AP/CH)
O L L L
ZONE2 PRE OUT MUTE Control
100
PA1/A1/PO17/
TIOCA6/TIOCB6
CLK MUTE O L L L
PLD Control pin (MUTE CLK SW) MUTE
Active="H"
101
PA0/A0/BC0#/PO16/
TIOCA6
PRE MUTE O L L L
PRE OUT MUTE Control
131
