Pin Pin Name Symbol I/O Pu/Pd
Lv
Cnv
STBY STOP
CEC
STBY
Function
102 PE7/IRQ7-A/D15
MN864778A
HAINT
I I I I
MN864778A HDMI Audio INT input
103 PE6/IRQ6-A/D14 MN864778 HINT I I I I
MN864778 HDMI INT input
104 PE5/IRQ5-A/D13
MN864778
HAINT
I I I I
MN864778 HDMI Audio INT input
105 PE4/D12 ISEL A I I I I
Input Selector Rotation detection input
（ENCODOR）※ Operate as VSEL B
106 PE3/D11 ISEL B I I I I
Input Selector Rotation detection input
（ENCODOR）※ Operate as VSEL A
107 PE2/D10 VOL CLK O L L L
FUNCTION/VOLUME Control(NJU72340A)
108 PE1/D9 VOL DATA O L L L
FUNCTION/VOLUME Control(NJU72340A)
109 PE0/D8 PLD WRITE O L L L
PLD/JTAGLINE switching
110 PD7/D7 JTAG TDO I L L L
JTAG I/F (PLD rewrite)
111 PD6/D6
JTAG TMS/
APLD CS
O/O L L L
JTAG I/F (PLD rewrite)/Audio PLD Control I/F
112 PD5/D5
JTAG TDI/APLD
DATA/DAC
DATA
O/O L L L
JTAG I/F (PLD rewrite)/Audio PLD Control I/F /
DAC Control
113 PD4/D4
JTAG TCK/
APLD CLK/DAC
CLK
O/O L L L
JTAG I/F (PLD rewrite)/Audio PLD Control I/F /
DAC Control
114 P64/CS4#-B VEXP STB O L L L
VIDEO Control EXPANDER Control pin
115 P63/CS3#-A/CS7#-A THERMAL A I SW3VPu I L I
PROTECTION detection pin(THERMAL A)
116 P62/CS2#-A/CS6#-A E SPI CS O N3VPu L L L
ETHERNET Communication Control pin (CY920)
117
P61/CS1#/CS2#-B/
CS5#-A/CS6#-B/
CS7#-B
DAC MS O L L L
DAC Control (PCM1690)
118
P60/CS0#/CS4#-A/
CS5#-B
DAC RST O L L L
DAC Control (PCM1690)
119 PD3/D3 VEXP CLK O L L L
VIDEO Control EXPANDER Control pin
120 PD2/D2 VEXP DATA O L L L
VIDEO Control EXPANDER Control pin
121 PD1/D1 FL CLK O L L L
FL Control pin
122 PD0/D0 FL DATA O L L L
FL Control pin
123 P97/AN15 DA POWER O L L L
DIGITAL POWER Contro (DA3.3V,DA1.2V) ON/
OFF SW ("H":ON)
124 P96/AN14 CEC POWER O L L
※
CEC STANDBY POWER Contro
(CEC5V,CEC3.3V,CEC1.8V)※CEC
STANDBY:MODE1=H,MODE2=H,MODE3=L
125 P95/AN13 DV POWER1 O L L
※
DIGITAL POWER Contro(VIDEO)(DV5V,DV3.3V) ※
CEC STANDBY:MODE1=H,MODE2=L,MODE3=L
126 P94/AN12 THERMAL B I SW3VPu I L I
PROTECTION detection pin(THERMAL B)
127 P93/AN11 MAIN POWER O L L L
MAIN POWER Control pin
128 P92/AN10 CPU POWER O L L L
MAIN CPU POWER Control pin(POWER ON : "H")
（CEC ON=STANDBY : "H")
129 P91/AN9 AMPSIGDET I I L I
AMP Supply current detection pin(AD)
130 VSS VSS - - - -
GND
131 P90/AN8 MODE I I I I
Destination switching input
132 VCC VCC - - - -
POWER pin
133 P47/IRQ15-B/AN7 DC DET/ASO I I I I
PROTECTION detection pin(DC DET)/(ASO) A/D
134 P46/IRQ14-B/AN6
H/P DET / MIC
DET
I I I I
Headphone detection pin/MIC detection pin A/
D
135 P45/IRQ13-B/AN5 KEY3 I SW3VPu I I I
KEY input ３(STANDBY : interrupt setting)
136 P44/IRQ12-B/AN4 KEY2 I SW3VPu I I I
KEY input ２(STANDBY : interrupt setting)
137 P43/IRQ11-B/AN3 KEY1 I SW3VPu I I I
KEY input １(STANDBY : interrupt setting)
138 P42/IRQ10-B/AN2 E SPI REQ I Pd I L I
ETHERNET Communication Control pin (CY920)
139 P41/IRQ9-B/AN1 CURRENT DET I I L I
AMP Supply current detection pin(AD)
140 AVSS AVSS - - - -
ANALOG GND
141 P40/IRQ8-B/AN0 CEC_IN I SW3VPu I I I
CEC-D signal input pin
142 VREF VREF - - - -
Reference voltage input
143 AVCC AVCC - - - -
ANALOG POWER
144
P05/IRQ13-A/TMO3/
RxD4/TCK
TCK/RXD
MITSUBISHI/
NC(NORMRAL)
I/I/I M3VPu -/-/I -/-/I I
E20Emulator Control signal/MITSUBISHI writer
rewrite/set normal:"input"
132
