Denon AVR-X1100W

FRONT
REF No. Part No. Part Name Remarks Q't
y
New
V
er
C1019 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C1020 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C1038 nsp CAP,ELECT(16V/47uF)-S CCEA1CKS470T 1
C1039 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 1
C1050 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1052 nsp CAP,ELECT(10V/220uF)-S CCEA1AKS221T 1
C1053-1055 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 3
C1065 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C1066 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1067 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C1068 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1071,1072 nsp CAP,CHIP(1608,50V/680pF,C0G)_SAMSUNG CCUS1H681JAS 2
C1073 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1076,1077 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 2
C1081 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1401 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1402 nsp CAP,ELECT(50V/1uF)-S CCEA1HKS1R0T 1
C1403 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 1
C1405 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T 1
C1406 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG CCUS1H473KCS 1
C1407 nsp CAP,ELECT(16V/100uF)-S CCEA1CKS101T 1
C1408 nsp CAP,CHIP(1608,50V/82pF,C0G)_SAMSUNG CCUS1H820JAS 1
C1410,1411 nsp CAP,ELECT(50V/1uF)-S CCEA1HKS1R0T 2
C1414 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1415 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
C1417 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1424 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1425,1426 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 2
OTHER PARTS GROUP
BK101,102 nsp BRACKET,FIP CMD1A572-V1 2
BK103 nsp BRACKET,PCB CMD1A629 1
BN101 nsp WIREASS'YB'D-B'DIN(9P,2MM,80MM,#28) CWB1A009080CC 1
BN104 nsp WIREASS'Y(5P,2.0MM,350MM,Shield)_USB CWB1C205350LC00 1
BN12A nsp WIREASS'YB'DtoB'D(CKM)(5P,2MM,80MM,#26) CWB1B005080CC 1
BN12B1 nsp WAFER,FFC1.25mm,ANGLE CJP27GB286ZN 1
BN131 nsp WIREASS'YLocking(YH)(3P,2MM,50MM,#28) CWB1A003050HC 1
CN102 nsp WAFER/ANGLE/2.5mm/07P CJP07GB03ZY 1
CN103 nsp LOCK-WAFER/ANGLE/2MMPITCH/3PIN CJP03GJ288ZY 1
CN104 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/3PIN CJP03GI288ZY 1
! F1001 943652000620S FUSE
(
372Series/100mA/TR5
)
CBA2D0100A3EYT 1
FL101 943172100150S V.F.D(FUTABA,18-BT-02GINK) CFL18BT021GINK 1
IC101 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
J1056/1057 nsp WIRE,COPPER(D0.6) S700 C3A206 2
J1059 nsp WIRE,COPPER(D0.6) S700 C3A206 1
J1061 nsp WIRE,COPPER(D0.6) S700 C3A206 1
J1064 nsp WIRE,COPPER(D0.6) S700 C3A206 1
JK101 943643101590S JACK,USBSTRAIGHT(BLACK1.5A) CJJ9X010Z 1
JK104 90M-YT004500R JACK,PHONES(6.35mm,SILVER) CJJ2E026Z 1
JK105 943643102930S JACK,STEREO,3.5mmMINI,BLACKMOLD CJJ2D029Z 1 *
L1001 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1003 nsp FERRITECHIPBEAD(4516/60R) CLZ9Z014V 1
L1004,1005 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
L1010-1013 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 4
L1401-1404 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 4
LD101 963262010460S L.E.D(Infraredlightemittingdiode) CVDSIR341ST3FT0 1
LUG11 nsp WIREASS'Y CWE8102100RV 1
LUG13 nsp WIREASS'Y CWE8102180RV 1
RC101 943262100140S SENSOR,REMOTE(37.9KHz) CRVHM238RT12 1
SW101 00D9430004402 SW,TACT CST1A012ZT 1
SW102/103 00D9430004402 SW,TACT S700 CST1A012ZT 2
SW104-106 00D9430004402 SW,TACT CST1A012ZT 3
SW107/108 00D9430004402 SW,TACT S700 CST1A012ZT 2
SW109-111 00D9430004402 SW,TACT CST1A012ZT 3
SW112-113 00D9430004402 SW,TACT S700 CST1A012ZT 3
SW115-118 00D9430004402 SW,TACT CST1A012ZT 4
SW119 00D9430004402 SW,TACT S700 CST1A012ZT 1
VR101 943671010330S ENCODER(16MM,24PULSES),W/CLICK CSR2A055Z 1
VR102 943671101000D ENCODER(16MM,12PULSES) CSR2A060Z 1 *
