Denon AVR-X1100W

MAIN
MAIN PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
D5106 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5206 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5306 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5406 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5506 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5606 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5706 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5801-5806 00D9430182609 DIODE,SWITCHING CVD1SS133MT 6
D5807 90M-HD302380R DIODE,ZENER,1/2W,3.6V CVDZJ3.6BT 1
D5808-5814 00D9430182609 DIODE,SWITCHING CVD1SS133MT 7
D5815 90M-HD302380R DIODE,ZENER,1/2W,3.6V CVDZJ3.6BT 1
D5816 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5817 90M-HD302360R DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT 1
D5818 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5819 90M-HE200390R DIODE,BRIDGE HVDGBJ1006 1
Q5105 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1 *
Q5106 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1 *
Q5107 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5108 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5205 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1 *
Q5206 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1 *
Q5207 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5208 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5305 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1 *
Q5306 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1 *
Q5307 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5308 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5405 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1 *
Q5406 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1 *
Q5407 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5408 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5505 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1 *
Q5506 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1 *
Q5507 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5508 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5605 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1 *
Q5606 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1 *
Q5607 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5608 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5705 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1 *
Q5706 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1 *
Q5707 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5708 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5801-5806 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 6
Q5807 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1
Q5808 943214500020S T.R,2SC3052 CVT2SC3052 1
Q5809 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q5810,5811 943214500020S T.R,2SC3052 CVT2SC3052 2
Q5812 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q5813 943214500020S T.R,2SC3052 CVT2SC3052 1
Q5814 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
IC501 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
RESISTOR GROUP
R5113 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5114 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5115,5116 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5117,5118 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5119-5122 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5123 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5124 nsp RES,CARBON(1/5W,180Kohm,J) CRD20TJ184T 1
R5125 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5126 252310006506S PTCTHEMISTORS,CHIP
(
115'C
)
CRTPRF18BB471Q
B
1
R5127 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5129 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5130,5131 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5132 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5133 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5213 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5214 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5215,5216 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5217,5218 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5219-5222 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5223 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5224 nsp RES,CARBON(1/5W,180Kohm,J) CRD20TJ184T 1
R5225 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5226 252310006506S PTCTHEMISTORS,CHIP
(
115'C
)
CRTPRF18BB471Q
B
1
R5227 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5229 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5230,5231 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5232 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5233 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5313 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5314 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5315,5316 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5317,5318 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5319-5322 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5323 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5324 nsp RES,CARBON(1/5W,180Kohm,J) CRD20TJ184T 1
R5325 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5326 252310006506S PTCTHEMISTORS,CHIP
(
115'C
)
CRTPRF18BB471Q
B
1
R5327 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5329 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5330,5331 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5332 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5333 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5413 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5414 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5415,5416 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
