Denon AVR-X1100W Service Manual

Error
Code
Details of Error code Display Coping strategies
5C
DSP, PLD etc. failed to receive the
rmware for rewriting sent from
CX870 (when timed out).
U p d a t i n g f a i l 5 C
Turn on the power again. Update will
start automatically.
5D
DSP, PLD etc. failed to receive the
rmware for rewriting sent from
CX870 (when an error occurred).
U p d a t i n g f a i l 5 D
Turn on the power again. Update will
start automatically.
5E
DSP, PLD etc. receive the cor-
rupted rmware data for rewriting
sent from CX870 (when the Check
Sum error occurred).
U p d a t i n g f a i l 5 E
Turn on the power again. Update will
start automatically.
5F
DSP, PLD etc. receive the cor-
rupted rmware data for rewriting
sent from CX870 (invalid data was
received).
U p d a t i n g f a i l 5 F
Turn on the power again. Update will
start automatically.
60
NACK was received when "P"
command was sent to DSP, PLD
etc.
U p d a t i n g f a i l 6 0
Turn on the power again. Update will
start automatically.
61
NACK was received when "I" com-
mand was sent to DSP, PLD etc.
U p d a t e C h e c k N G 6 1
Turn on the power again. Update will
start automatically.
80
Failed to obtain ash information
before erasing the ash.
U p d a t i n g f a i l 8 0
Turn on the power again. Update will
start automatically.
81
Failed to erase the data before
rewriting the ash.
U p d a t i n g f a i l 8 1
Turn on the power again. Update will
start automatically.
82
Failed to receive the serial ash
rmware for rewriting sent from
CX870 (when timed out).
U p d a t i n g f a i l 8 2
Turn on the power again. Update will
start automatically.
83
Failed to receive the serial ash
rmware for rewriting sent from
CX870 (when an error occurred).
U p d a t i n g f a i l 8 3
Turn on the power again. Update will
start automatically.
84
Failed to receive the serial ash
rmware for rewriting sent from
CX870 (when the Check Sum error
occurred).
U p d a t i n g f a i l 8 4
Turn on the power again. Update will
start automatically.
85
Failed to receive the the serial
ash rmware for rewriting sent
from CX870 (invalid data was
received).
U p d a t i n g f a i l 8 5
Turn on the power again. Update will
start automatically.
86
Data was found to be corrupt dur-
ing verication after the ash was
rewritten.
U p d a t i n g f a i l 8 6
Turn on the power again. Update will
start automatically.
A0
Failed to acquire the IP address
(AutoIP) before CX870 rewrite
(Application Mode).
C o n n e c t i o n F a i l A 0
Check the network connection. Update
in an environment where there is a
small network load.
A1
Failed to acquire the IP address
before CX870 rewrite (Application
Mode) (whern timed out).
C o n n e c t i o n F a i l A 1
Check the network connection. Update
in an environment where there is a
small network load.
A2
Unauthorized login DPMS access
notication was received when
rewriting the CX870 related rm-
ware (Application Mode).
L o g i n f a i l e d A 2
Check the network connection. Update
in an environment where there is a
small network load.
67

Denon AVR-X1100W Specifications

General

Receiver type	Surround
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
Supported radio bands	AM, FM
Optical drive included	No
Display	VFL
Product color	Black
Audio decoders	Dolby Digital 5.1, Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Plus, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8600 g
