o
Connection 3 : Connection through the video output connector and external power amplifiers
The audio signals of this unit’s ZONE2 and ZONE3 audio output connectors are played on the ZONE2 and ZONE3 power amplifiers.
.
R
L
IN
VIDEO
VIDEO
COMPONENT VIDEO
YPB PR
IN
AUX IN
AUX IN
Power amplifier
ZONE3
ZONE2
or
This unit
MAIN ZONE
Power amplifier
R
L
Contents
Connections Playback Settings Tips Appendix
181
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X6700H

Preview: Quick Start Guide
Quick Start Guide14 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X6700H and is the answer not in the manual?

Denon AVR-X6700H Specifications

General IconGeneral
Channels11.2
Power Output140W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Speaker Impedance4-16 ohms
Input Sensitivity/Impedance200mV / 47k ohms
HDMI Inputs8
HDMI Outputs3
HDCP SupportHDCP 2.3
HDR CompatibilityHDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)eARC
Video Upscaling8K
BluetoothYes
Wi-FiYes
EthernetYes
Voice Assistant SupportAmazon Alexa, Google Assistant, Apple Siri
Phono InputYes
Zone Audio Output3 Zones
Room CalibrationAudyssey MultEQ XT32
Frequency Response10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion0.05%
Signal-to-Noise Ratio102dB
HDMI Support4K/120Hz, 8K/60Hz
USB Port1
Streaming ServicesAirPlay 2, HEOS, Spotify, Tidal, Deezer, Amazon Music, Pandora, SiriusXM
Audio DecodingDolby Atmos, DTS:X, Auro-3D
