Denon AVR-X6700H User Manual

o
Connecting the speaker cables
Carefully check the left (L) and right (R) channels and + (red) and –
(black) polarities on the speakers being connected to this unit, and be
sure to connect the channels and polarities correctly.
1
Peel off about 3/8 inch (10 mm) of sheathing from the
tip of the speaker cable, then either twist the core wire
tightly or terminate it.
.
2
Turn the speaker terminal counterclockwise to loosen it.
.
3
Insert the speaker cable’s core wire to the hilt into the
speaker terminal.
.
4
Turn the speaker terminal clockwise to tighten it.
.
o
Connecting the subwoofer
Use a subwoofer cable to connect the subwoofer. Two subwoofers can
be connected to this unit.
To use two subwoofers, set “Subwoofer” to “2 spkrs” in the “Speaker
Config.” setting. (v p. 247)
The level and distance can be set separately for Subwoofer 1 and
Subwoofer 2.
.
ASSIGNABLE ASSIGNABLE
ASSIGNABLE
ASSIGNABLE
SPEAKERS
SW1 SW2
Contents
Connections Playback Settings Tips Appendix
42
Front panel Display Rear panel Remote Index

Denon AVR-X6700H Specifications

General

Channels	11.2
Power Output	140W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Speaker Impedance	4-16 ohms
Input Sensitivity/Impedance	200mV / 47k ohms
HDMI Inputs	8
HDMI Outputs	3
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Video Upscaling	8K
Bluetooth	Yes
Wi-Fi	Yes
Ethernet	Yes
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Phono Input	Yes
Zone Audio Output	3 Zones
Room Calibration	Audyssey MultEQ XT32
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05%
Signal-to-Noise Ratio	102dB
HDMI Support	4K/120Hz, 8K/60Hz
USB Port	1
Streaming Services	AirPlay 2, HEOS, Spotify, Tidal, Deezer, Amazon Music, Pandora, SiriusXM
Audio Decoding	Dolby Atmos, DTS:X, Auro-3D
