Denon AVR-X6700H User Manual

o
Speakers for ZONE2 / Speakers for ZONE3 /
Speakers for ZONE2/3 / Speakers for Bi-Amp /
Speakers for 2ch / Speakers for Front B
When “Assign Mode” is set to “9.1ch + ZONE2”, “9.1ch + ZONE3”,
“9.1ch + ZONE2/3-MONO”, “7.1ch + ZONE2/3”, “9.1ch (Bi-Amp)” or
“9.1ch + Front B” in the menu, select the speaker terminal from which
to output the channels to which the internal amplifier is assigned.
(v p. 238)
HEIGHT 1:
The assigned channels are output from
the HEIGHT1 speaker terminals. The
height, ceiling, and Dolby Atmos Enabled
channels cannot be used.
HEIGHT 2:
The assigned channels are output from
the HEIGHT2 speaker terminals. Up to
one set of height, ceiling, and Dolby
Atmos Enabled channels can be used.
HEIGHT3/FRONT WIDE
(Default)：
The assiend channels are output from the
HEIGHT3/FRONT WIDE speaker
terminals.
Two sets of height, ceiling and Dolby
Enabled speakers can be used.
Front wide speakers cannot be used.
o
Floor
Select the floor speakers location.
5ch & SB & FW:
This layout combines a surround back or
front wide speaker with the basic 5-
channel layout.
5ch & SB
(Default):
This layout combines a surround back
speaker with the basic 5-channel layout.
5ch & FW:
This layout combines a front wide
speaker with the basic 5-channel layout.
5ch:
This is a basic 5-channel layout that uses
front speakers, center speakers and
surround speakers.
Contents Connections Playback Settings Tips Appendix
240
Front panel Display Rear panel Remote Index

Denon AVR-X6700H Specifications

General

Channels	11.2
Power Output	140W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Speaker Impedance	4-16 ohms
Input Sensitivity/Impedance	200mV / 47k ohms
HDMI Inputs	8
HDMI Outputs	3
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Video Upscaling	8K
Bluetooth	Yes
Wi-Fi	Yes
Ethernet	Yes
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Phono Input	Yes
Zone Audio Output	3 Zones
Room Calibration	Audyssey MultEQ XT32
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05%
Signal-to-Noise Ratio	102dB
HDMI Support	4K/120Hz, 8K/60Hz
USB Port	1
Streaming Services	AirPlay 2, HEOS, Spotify, Tidal, Deezer, Amazon Music, Pandora, SiriusXM
Audio Decoding	Dolby Atmos, DTS:X, Auro-3D
