Denon AVR-X6700H - Connecting the Power Cord

To Next Page

To Previous Page

Connecting the power cord

After completing all the connections, insert the power plug into the power outlet.

(AC 120 V, 60 Hz)

To household power outlet

Power cord (supplied)
